CVM-C11
3�5�18�- MEASURING SINGLE-PHASE NETWORKS, PHASE TO NEUTRAL, WITH A 2-WIRE CONNEC-
TION, CVM-C11-FLEX-IN-485-ICT2 MODEL
L1
N
Figure 21: Measuring Single-Phase Networks, phase to neutral, with a 2-wire connection (CVM-C11-FLEX-IN-485-ICT2)�
Instruction Manual
Measurement system:
Alimentación Auxiliar
Power Supply
A1(+)
POWER SUPPLY
A1(+)
U
L1
U
L1
U
N
L1 U
L1
a
b
A B
CARGA /LOAD
It is mandatory connect the SHLD terminal of the probe.
2-1Ph
A2(-)
OUTPUTS INPUTS RS-485
A2(-) ROC R01 R02 DOC D01 D02 DIC DI1 DI2 A(+) B(-)
U U
OUT+ OUT- SHLD
L3 L2
U U N
IN
IL1 IL2 IL3
L2 L3
OUT- SHLD
N
IL1
31
