3�5�15�- MEASURING SINGLE-PHASE NETWORKS, PHASE TO PHASE, WITH A 2-WIRE CONNECTION,

CVM-C11-FLEX-IN-485-ICT2 MODEL

Figure 18: Measuring Single-Phase Networks, phase to phase, with a 2-wire connection (CVM-C11-FLEX-IN-485-ICT2)�
28
Measurement system:
U U
L1 L2
a
b
A B
L1
L2
It is mandatory connect the SHLD terminal of the probe.
2-2Ph
Alimentación Auxiliar
Power Supply
A1(+) A2(-)
POWER SUPPLY OUTPUTS
A1(+) A2(-) ROC R01 R02 DOC D01 D02
U
U U OUT+
L1
L3 L2
U U U N IL1 IL2
L1 L2 L3
IL1
U U
L1 L2
CARGA /LOAD
INPUTS RS-485
DIC DI1 DI2 A(+) B(-)
OUT- SHLD
IL3 IN
OUT- SHLD
