  • Page 1 Power analyzer CVM-C11 INSTRUCTION MANUAL (M361B01-03-23B)
  • Page 2 CVM-C11 Instruction Manual...

  • Page 3: Safety Precautions

    CIRCUTOR S�A�U� reserves the right to make modifications to the device or the unit specifications set out in this instruction manual without prior notice. CIRCUTOR S�A�U� on its web site, supplies its customers with the latest versions of the device specifi- cations and the most updated manuals.

  • Page 4: Table Of Contents

    3�4�1�- CVM-C11-ITF-IN-485-ICT2 AND CVM-C11-MC-IN-485-ICT2 MODELS ��������������������������������������������������������11 3�4�2�- CVM-C11-ITF-IN-ETH-ICT2 MODEL ������������������������������������������������������������������������������������������������������������� 12 3�4�3�- CVM-C11-FLEX-IN-485-ICT2 MODEL ���������������������������������������������������������������������������������������������������������� 13 3�5�- CONNECTION DIAGRAM ����������������������������������������������������������������������������������������������������������������������������������������� 14 3�5�1�- MEASURING THREE-PHASE NETWORKS WITH A 4-WIRE CONNECTION, CVM-C11-ITF-IN-xxx-ICT2 MODEL���������������������������������������������������������������������������������������������������������������������������������������������������������������������� 14 3�5�2�- MEASURING THREE-PHASE NETWORKS WITH A 4-WIRE CONNECTION, CVM-C11-MC-IN-485-ICT2 MODEL���������������������������������������������������������������������������������������������������������������������������������������������������������������������� 15 3�5�3�- MEASURING THREE-PHASE NETWORKS WITH A 4-WIRE CONNECTION, CVM-C11-FLEX-IN-485-ICT2...
  • Page 5 6�2�- SECONDARY VOLTAGE ������������������������������������������������������������������������������������������������������������������������������������������ 58 6�3�- PRIMARY CURRENT ����������������������������������������������������������������������������������������������������������������������������������������������59 6�4�- SECONDARY CURRENT (CVM-C11-ITF-IN-xxx-ICT2 Model) ��������������������������������������������������������������������������������59 6�5�- PRIMARY NEUTRAL CURRENT ���������������������������������������������������������������������������������������������������������������������������� 60 6�6�- SECONDARY NEUTRAL CURRENT (CVM-C11-ITF-IN-xxx-ICT2 Model) ��������������������������������������������������������������� 61 6�7�- NUMBER OF QUADRANTS ������������������������������������������������������������������������������������������������������������������������������������� 61 6�8�- MEASUREMENT CONVENTION �����������������������������������������������������������������������������������������������������������������������������62 6�9�- TYPE OF INSTALLATION ����������������������������������������������������������������������������������������������������������������������������������������63 6�10�- TYPE OF INTEGRATION OF THE MAXIMUM DEMAND �����������������������������������������������������������������������������������������63...
  • Page 6 CVM-C11 6�31�- RS-485 COMMUNICATIONS: PROTOCOL �������������������������������������������������������������������������������������������������������������86 6�32�- MODBUS PROTOCOL: BAUD RATE �����������������������������������������������������������������������������������������������������������������������87 6�33�- MODBUS PROTOCOL: PERIPHERAL NUMBER ����������������������������������������������������������������������������������������������������87 6�34�- MODBUS PROTOCOL: PARITY ����������������������������������������������������������������������������������������������������������������������������� 88 6�35�- MODBUS PROTOCOL: NUMBER OF DATA BITS ����������������������������������������������������������������������������������������������������89 6�36�- MODBUS PROTOCOL: NUMBER OF STOP BITS ���������������������������������������������������������������������������������������������������89 6�37�- BACnet PROTOCOL: BAUD RATE �������������������������������������������������������������������������������������������������������������������������...

  • Page 7: Revision Log

    CVM-C11 REVISION LOG Table 1: Revision log� Date Revision Description 09/22 M361B01-03-22A Initial Version Changes in the following sections: 01/23 M361B01-03-23A 3.4.7. - 4.1. - 5.1. - 5.1.3. - 6.9. - 7.3.6. - 7.3.8.5. - 8. - Annex A Changes in the following sections: 2.

  • Page 8: 1�- Verification Upon Reception

    CIRCUTOR's after-sales service. 2.- PRODUCT DESCRIPTION The CVM-C11 device measures, calculates and displays the main electrical parameters of the following networks: single-phase, two-phase, with and without neutral, balanced three-phase, with ARON meas- urements or unbalanced. The measurement will be taken in RMS with the three AC voltage inputs and four current inputs.

  • Page 9: 3�- Device Installation

    The CVM-C11 device must be installed by authorised and qualified staff. The power supply plug must be disconnected and measuring systems switched off before handling, al- tering the connections or replacing the device.

  • Page 10: 3�3�- Cvm-C11-Flex-In-485-Ict2: Rogowski Sensors

    The flexibility of the sensor allows it to measure an alternating current irrespective of the position of the conductor. CIRCUTOR has 1 Rogowski sensor model that can be used with the CVM-C11-FLEX-IN-485-ICT2: MFC- FLEX. Note: For more information, consult the corresponding sensor guide.

  • Page 11: 3�4�- Device Terminals

    A(+) B(-) 16 17 18 19 20 21 22 23 24 25 Figure 1: CVM-C11-ITF-IN-485-ICT2 and CVM-C11-MC-IN-485-ICT2 terminals� Table 4: List of terminals of the CVM-C11-ITF-IN-485-ICT2 and CVM-C11-MC-IN-485-ICT2� Device terminals 1 : A1(+), Power supply 14 : U Voltage input L1...

  • Page 12: 3�4�2�- Cvm-C11-Itf-In-Eth-Ict2 Model

    D0C D01 D02 A(+) B(-) 16 17 18 19 20 21 22 23 24 25 Figure 2: CVM-C11-ITF-IN-ETH-ICT2 terminals� Table 5: List of terminals of the CVM-C11-ITF-ETH-485-ICT2� Device terminals 1 : A1(+), Power supply 14 : U Voltage input L1...

  • Page 13: 3�4�3�- Cvm-C11-Flex-In-485-Ict2 Model

    SHLD 22 23 16 17 18 19 20 21 Figure 3: CVM-C11-FLEX-IN-485-ICT2 terminals� Table 6: List of terminals of the CVM-C11-FLEX-IN-485-ICT2� Device terminals 1 : A1(+), Power supply 13 : B(-), RS-485 2 : A2(-), Power supply 14 : U...

  • Page 14: 3�5�- Connection Diagram

    CVM-C11 3�5�- CONNECTION DIAGRAM 3�5�1�- MEASURING THREE-PHASE NETWORKS WITH A 4-WIRE CONNECTION, CVM-C11-ITF-IN- xxx-ICT2 MODEL 4-3Ph Measurement system: Alimentación Auxiliar Power Supply A1(+) A2(-) POWER SUPPLY OUTPUTS INPUTS RS-485 A1(+) A2(-) ROC R01 R02 DOC D01 D02 A(+) B(-) CARGA /LOAD Figure 4: Three-Phase measuring with a 4-wire connection (CVM-C11-ITF-IN-xxx-ICT2)�...

  • Page 15: 3�5�2�- Measuring Three-Phase Networks With A 4-Wire Connection, Cvm-C11-Mc-In-485-Ict2

    CVM-C11 3�5�2�- MEASURING THREE-PHASE NETWORKS WITH A 4-WIRE CONNECTION, CVM-C11-MC-IN- 485-ICT2 MODEL 4-3Ph Measurement system: Alimentación Auxiliar Power Supply A1(+) A2(-) POWER SUPPLY OUTPUTS INPUTS RS-485 A2(-) A(+) B(-) A1(+) ROC R01 R02 DOC D01 D02 CARGA /LOAD Figure 5: Three-Phase measuring with a 4-wire connection (CVM-C11-MC-IN-485-ICT2)�...

  • Page 16: 3�5�3�- Measuring Three-Phase Networks With A 4-Wire Connection, Cvm-C11-Flex-In-485-Ict2

    CVM-C11 3�5�3�- MEASURING THREE-PHASE NETWORKS WITH A 4-WIRE CONNECTION, CVM-C11-FLEX-IN- 485-ICT2 MODEL 4-3Ph Measurement system: Alimentación Auxiliar Power Supply A1(+) A2(-) POWER SUPPLY OUTPUTS INPUTS RS-485 A2(-) A(+) B(-) A1(+) ROC R01 R02 DOC D01 D02 OUT+ OUT- SHLD OUT-...

  • Page 17: 3�5�4�- Measuring Three-Phase Networks With A 3-Wire Connection, Cvm-C11-Itf-In-Xxx-Ict2

    CVM-C11 3�5�4�- MEASURING THREE-PHASE NETWORKS WITH A 3-WIRE CONNECTION, CVM-C11-ITF-IN- xxx-ICT2 MODEL 3-3Ph Measurement system: Alimentación Auxiliar Power Supply A1(+) A2(-) POWER SUPPLY OUTPUTS INPUTS RS-485 A1(+) A2(-) R01 R02 D01 D02 A(+) B(-) CARGA /LOAD Figure 7: Three-Phase measuring with a 3-wire connection (CVM-C11-ITF-IN-xxx-ICT2)�...

  • Page 18: 3�5�5�- Measuring Three-Phase Networks With A 3-Wire Connection, Cvm-C11-Mc-In-485-Ict2

    CVM-C11 3�5�5�- MEASURING THREE-PHASE NETWORKS WITH A 3-WIRE CONNECTION, CVM-C11-MC-IN- 485-ICT2 MODEL 3-3Ph Measurement system: Alimentación Auxiliar Power Supply A1(+) A2(-) POWER SUPPLY OUTPUTS INPUTS RS-485 A2(-) A(+) B(-) A1(+) R01 R02 D01 D02 CARGA /LOAD Figure 8: Three-Phase measuring with a 3-wire connection (CVM-C11-MC-IN-485-ICT2)�...

  • Page 19: 3�5�6�- Measuring Three-Phase Networks With A 3-Wire Connection, Cvm-C11-Flex-In-485-Ict2

    CVM-C11 3�5�6�- MEASURING THREE-PHASE NETWORKS WITH A 3-WIRE CONNECTION, CVM-C11-FLEX-IN- 485-ICT2 MODEL 3-3Ph Measurement system: Alimentación Auxiliar Power Supply A1(+) A2(-) POWER SUPPLY OUTPUTS INPUTS RS-485 A1(+) A2(-) R01 R02 D01 D02 A(+) B(-) OUT+ OUT- SHLD OUT- SHLD IL1 IL2 IL3 CARGA /LOAD Figure 9: Three-Phase measuring with a 3-wire connection (CVM-C11-FLEX-IN-485-ICT2)�...

  • Page 20: 3�5�7�- Measuring Three-Phase Networks With A 3-Wire Connection And Transformers With An Aron Connection, Cvm-C11-Itf-In-Xxx-Ict2 Models

    Measurement system: Alimentación Auxiliar Power Supply A1(+) A2(-) POWER SUPPLY OUTPUTS INPUTS RS-485 A2(-) A(+) B(-) A1(+) R01 R02 D01 D02 CARGA /LOAD Figure 10: Three-Phase measuring with a 3-wire connection and transformers with an ARON connection (CVM-C11-ITF-IN-xxx- ICT2)� Instruction Manual...

  • Page 21: 3�5�8�- Measuring Three-Phase Networks With A 3-Wire Connection And Transformers With An Aron Connection, Cvm-C11-Mc-In-485-Ict2 Model

    R01 R02 D01 D02 CARGA /LOAD Figure 11: Three-Phase measuring with a 3-wire connection and transformers with an ARON connection (CVM-C11-MC-IN-485- ICT2)� Note: Do not connect MC current transformers to ground. The MC transformer secondary value is set to 0.250 A (fixed value).

  • Page 22: 3�5�9�- Measuring Three-Phase Networks With A 3-Wire Connection And Transformers With An Aron Connection, Cvm-C11-Flex-In-485-Ict2 Model

    A1(+) R01 R02 D01 D02 OUT+ OUT- SHLD OUT- SHLD CARGA /LOAD Figure 12: Three-Phase measuring with a 3-wire connection and transformers with an ARON connection (CVM-C11-FLEX-IN-485- ICT2)� It is mandatory connect the SHLD terminal of the probe. Instruction Manual...

  • Page 23: Models

    3�5�10�- MEASURING TWO-PHASE NETWORKS WITH A 3-WIRE CONNECTION, CVM-C11-ITF-IN-xxx- ICT2 MODELS 3-2Ph Measurement system: Alimentación Auxiliar Power Supply A1(+) A2(-) POWER SUPPLY OUTPUTS INPUTS RS-485 A2(-) A(+) B(-) A1(+) R01 R02 D01 D02 CARGA /LOAD Figure 13: Measuring Two-Phase Networks with a 3-wire connection (CVM-C11-ITF-IN-xxx-ICT2)� Instruction Manual...
  • Page 24 R01 R02 D01 D02 A(+) B(-) CARGA /LOAD Figure 14: Measuring Two-Phase Networks with a 3-wire connection (CVM-C11-MC-IN-485-ICT2)� Note: Do not connect MC current transformers to ground. The MC transformer secondary value is set to 0.250 A (fixed value). Instruction Manual...

  • Page 25: 3�5�12�- Measuring Two-Phase Networks With A 3-Wire Connection, Cvm-C11-Flex-In-485-Ict2

    RS-485 A2(-) A1(+) R01 R02 D01 D02 A(+) B(-) OUT+ OUT- SHLD OUT- SHLD IL1 IL2 CARGA /LOAD Figure 15: Measuring Two-Phase Networks with a 3-wire connection (CVM-C11-FLEX-IN-485-ICT2)� It is mandatory connect the SHLD terminal of the probe. Instruction Manual...

  • Page 26: Cvm-C11-Itf-In-Xxx-Ict2 Models

    CVM-C11-ITF-IN-xxx-ICT2 MODELS 2-2Ph Measurement system: Alimentación Auxiliar Power Supply A1(+) A2(-) POWER SUPPLY OUTPUTS INPUTS RS-485 A1(+) A2(-) R01 R02 D01 D02 A(+) B(-) CARGA /LOAD Figure 16: Measuring Single-Phase Networks, phase to phase, with a 2-wire connection (CVM-C11-ITF-IN-xxx-ICT2)� Instruction Manual...

  • Page 27: Cvm-C11-Mc-In-485-Ict2 Model

    D01 D02 A(+) B(-) CARGA /LOAD Figure 17: Measuring Single-Phase Networks, phase to phase, with a 2-wire connection (CVM-C11-MC-IN-485-ICT2)� Note: Do not connect MC current transformers to ground. The MC transformer secondary value is set to 0.250 A (fixed value).

  • Page 28: Cvm-C11-Flex-In-485-Ict2 Model

    A1(+) A2(-) R01 R02 D01 D02 A(+) B(-) OUT+ OUT- SHLD OUT- SHLD CARGA /LOAD Figure 18: Measuring Single-Phase Networks, phase to phase, with a 2-wire connection (CVM-C11-FLEX-IN-485-ICT2)� It is mandatory connect the SHLD terminal of the probe. Instruction Manual...

  • Page 29: Cvm-C11-Itf-In-Xxx-Ict2 Models

    TION, CVM-C11-ITF-IN-xxx-ICT2 MODELS 2-1Ph Measurement system: Alimentación Auxiliar Power Supply A1(+) A2(-) POWER SUPPLY OUTPUTS INPUTS RS-485 A1(+) A2(-) R01 R02 D01 D02 A(+) B(-) CARGA /LOAD Figure 19: Measuring Single-Phase Networks, phase to neutral, with a 2-wire connection (CVM-C11-ITF-IN-xxx-ICT2)� Instruction Manual...

  • Page 30: Cvm-C11-Mc-In-485-Ict2 Model

    D01 D02 A(+) B(-) CARGA /LOAD Figure 20: Measuring Single-Phase Networks, phase to neutral, with a 2-wire connection (CVM-C11-MC-IN-485-ICT2)� Note: Do not connect MC current transformers to ground. The MC transformer secondary value is set to 0.250 A (fixed value).

  • Page 31: Cvm-C11-Flex-In-485-Ict2 Model

    A1(+) A2(-) R01 R02 D01 D02 A(+) B(-) OUT+ OUT- SHLD OUT- SHLD CARGA /LOAD Figure 21: Measuring Single-Phase Networks, phase to neutral, with a 2-wire connection (CVM-C11-FLEX-IN-485-ICT2)� It is mandatory connect the SHLD terminal of the probe. Instruction Manual...

  • Page 32: Cvm-C11-Itf-In-Xxx-Ict2 Models

    Note: Installation available from version C11.1005.230119 of the device. 3-3IT Measurement system: Alimentación Auxiliar Power Supply A1(+) A2(-) POWER SUPPLY OUTPUTS INPUTS RS-485 A2(-) A(+) B(-) A1(+) R01 R02 D01 D02 CARGA /LOAD Figure 22: Measuring three-phase networks with a 3-wire and earth connection (CVM-C11-ITF-IN-xxx-ICT2)� Instruction Manual...

  • Page 33: Cvm-C11-Mc-In-485-Ict2 Model

    R01 R02 D01 D02 CARGA /LOAD Figure 23: Measuring three-phase networks with a 3-wire and earth connection (CVM-C11-MC-IN-485-ICT2)� Note: Do not connect MC current transformers to ground. The MC transformer secondary value is set to 0.250 A (fixed value). Instruction Manual...

  • Page 34: 3�5�21�- Measuring Three-Phase Networks With A 3-Wire And Earth Connection

    A1(+) R01 R02 D01 D02 OUT+ OUT- SHLD OUT- SHLD IL1 IL2 IL3 IN CARGA /LOAD Figure 24: Measuring three-phase networks with a 3-wire and earth connection (CVM-C11-FLEX-IN-485-ICT2)� It is mandatory connect the SHLD terminal of the probe. Instruction Manual...

  • Page 35: 4�- Operation

    CVM-C11 4.- OPERATION The CVM-C11 is a four-quadrant power analyzer (consumption and generation). The device can operate according to three different measurement conventions: CIRCUTOR measurement convention.  IEC 61557-12 measurement convention.  IEEE 1459 measurement convention.  The measurement convention is configured in the setup menu, see “6.8.- MEASUREMENT CONVENTION”.

  • Page 36: 4�1�- Measuring Parameters

    III = Three-phase, ∑= Total, MAX = Maximum value, MIN = Minimum value, M = Measured value, C= Calculated value, M/C = Measured value (M) if the Neutral transformer has been connected, if not the value is calculated (C). Table 7: Measuring parameters of the CVM-C11 (4-3Ph installation)� 4-3Ph Parameter...
  • Page 37 CVM-C11 Table 7 (Continuation): Measuring parameters of the CVM-C11 (4-3Ph installation)� 4-3Ph Parameter L2 L3 L12 L23 L31 ∑ MAX Maximum Demand of inductive Reactive Power Maximum Demand of capacitive Reactive Power Table 8: Measuring parameters of the CVM-C11 (3-3Ph installation)�...
  • Page 38 CVM-C11 Table 9 (Continuation): Measuring parameters of the CVM-C11 (3-Aron installation)� 3-Aron Parameter L2 L3 L12 L23 L31 ∑ MAX Active power Apparent power Inductive Reactive Power - Consumption Inductive Reactive Power - Generation Capacitive Reactive Power -Consumption Capacitive Reactive Power - Generation Cos φ...
  • Page 39 CVM-C11 Table 11: Measuring parameters of the CVM-C11 (2-2Ph installation)� 2-2Ph Parameter ∑ MAX Voltage THD Voltage Voltage harmonics Current THD Current Current harmonics Frequency Active power Apparent power Inductive Reactive Power - Consumption Inductive Reactive Power - Generation Capacitive Reactive Power -Consumption Capacitive Reactive Power - Generation Cos φ...
  • Page 40 CVM-C11 Table 12 (Continuation): Measuring parameters of the CVM-C11 (2-1Ph installation)� 2-1Ph Parameter ∑ MAX Maximum Demand of Apparent Power Maximum Demand of inductive Reactive Power Maximum Demand of capacitive Reactive Power Table 13: Measuring parameters of the CVM-C11 (3-3IT installation)�...

  • Page 41: 4�1�1�- Thd Calculation

    CVM-C11 Table 14 (Continuation): Measuring parameters of the CVM-C11 (Global)� Parameter T1 T2 T3 ∑ Cost - Generation Emissions - Consumption Emissions - Generation No. of hours 4�1�1�- THD CALCULATION The device can calculate the Total Harmonic Distortion (THD) using the fundamental component of the signal (THD) or the effective component (RMS) (thd).

  • Page 42: 4�2�- Display

    Sliding window Calculation time Integration period Figure 29: Sliding window� The CVM-C11 calculates the maximum demand of the following:  Current of the L1, L2, L3 and three-phase.  Three-Phase Active Power.  Three-Phase Apparent Power.  Three-Phase Inductive Reactive Power.

  • Page 43: 4�2�1�- Cos Φ - Pf (Power Factor)

    CVM-C11  The data area, which displays all the values measured by the device. The units and status area, which displays the different statuses, units and device information Table 15 Table 15:Display icons� Icon Description Icon Description Analog bar, where the % of the current Analyzer profile.

  • Page 44: 4�3�- Keyboard Functions

    The current is referenced in its full scale. (100% is the full scale of the device and a value above 100% indicates that it is out of range). 4�3�- KEYBOARD FUNCTIONS The CVM-C11 has 3 keys that allow you to browse between the various screens and program the device. Keyboard Figure 33: CVM-C11 keyboard�...
  • Page 45 CVM-C11 Key functions on harmonics screens ( Table 17 Table 17: Key functions on harmonics screens� Short keystroke Long keystroke (3 s) Output of the harmonics screens. Next screen. Browsing the different types of harmonics. Accessing the programming menu. Key functions on the programming menu, query mode ( Table 18 Table 18: Key functions on the programming menu, query mode�...

  • Page 46: 4�4�- Led Indicators

    - ALARM, red color, indicates that an alarm has been activated if it is on. LED ON LED Alarm Figure 34: LED Indicators of the CVM-C11� 4�5�- RELAYS El CVM-C11 has 2 alarm relays (terminals 3, 4 and 5 on ) fully programmable, see Figure 1 “6.25.- PRO- �...

  • Page 47: 4�6�- Digital Inputs

    Logic input Tariff selection Logic input Tariff selection 4�7�- DIGITAL OUTPUTS The CVM-C11 has two NPN transistors outputs (terminals 6, 7 and 8 on ), fully programmable, Figure 1 “6.27.- PROGRAMMING ALARM 3 (DIGITAL OUTPUT T1)” “6.28.- PROGRAMMING ALARM 4 (DIGITAL OUTPUT T2)”.

  • Page 48: 5�- Display

    CVM-C11 5.- DISPLAY The CVM-C11 has 3 operation profiles. The display screens will be opened for the corresponding profile:  Analyzer profile.  Electrical energy efficiency profile, e  User profile. Use the key to jump between the different profiles.
  • Page 49 CVM-C11 Active Power L1 Active Power L2 Active Power L3 Active Power Total, ∑ The generation values are not measured when the 2 quadrant option is selected. 3-3IT. Not available for installation types Apparent Power L1 Apparent Power L2 Apparent Power L3 Apparent Power Total, ∑...

  • Page 50: 5�1�1�- Maximum And Minimum Values

    CVM-C11 THD Voltage L1 THD Voltage L2 THD Voltage L3 THD Current L1 THD Current L2 THD Current L3 Power factor L1 Power factor L2 Power factor L3 Power factor III COS φ L1 COS φ L2 COS φ L3 COS φ...

  • Page 51: 5�1�2�- Maximum Demand

    CVM-C11 Figure 36: Analyzer profile screen displaying the maximum values� To see the minimum values of the screen being displayed, press the key for 3 seconds. These are displayed for 30 seconds. The symbol will be displayed. The maximum and minimum values are reset on the programming menu. ( “6.17.- DELETING MAXIMUM...

  • Page 52: 5�1�3�- Detection Of Incorrect Direction Of Rotation

    CVM-C11 5�1�3�- DETECTION OF INCORRECT DIRECTION OF ROTATION The device has a system for detecting the incorrect direction of rotation of the voltages. In other words, if each of the voltages has been correctly connected to the appropriate terminal, L1 to terminal U...
  • Page 53 CVM-C11 Active Energy Tariff 1 Active Energy Tariff 2 Active Energy Tariff 3 Total Active Energy, ∑ Consumption and generation values only available for the 4 quad- rant option. Apparent Energy Tariff 1 Apparent Energy Tariff 2 Apparent Energy Tariff 3 Total Apparent Energy, ∑...

  • Page 54: 5�3�- User Profile

    This profile is identified with the symbol at the top of the screen ( Figure 38 Figure 38: Screen of the CVM-C11 with the user profile� This profile displays the screens selected in the programming menu ( “6.14.- SELECTING THE OPERATION PROFILE”...

  • Page 55: 5�4�- Harmonics

    Harmonics are displayed as shown on Figure 39 Harmonic type Harmonic value Harmonic order Figure 39: CVM-C11 harmonics screen� The key jumps to the next harmonic screen. Press key to display the different types of harmonics: • Voltage harmonics L1- L2 - L3 •...

  • Page 56: 6�- Configuration

    CVM-C11 6.- CONFIGURATION To enter the configuration menu press the key for 3 seconds. The home screen of the menu indicates whether the menu is locked or not:  UnLOC(unlocked): When you enter the programming menu you can view and modify the programming.

  • Page 57: 6�1�- Primary Voltage

    CVM-C11 To access the first programming step, press the key. The programming parameters are validated as follows:  When on reaching the last point on the programming menu (“ 6.40.- LOCKING THE PROGRAM- ”) the key is pressed MING  At any point in the programming, by pressing the key for 3 seconds.

  • Page 58: 6�2�- Secondary Voltage

    CVM-C11 Voltage ratio x Primary Current < 600000 Note: The ratio is the relation between the primary and the secondary. Press key to access the next programming step. 6�2�- SECONDARY VOLTAGE On this screen the voltage transformer secondary is programmed.

  • Page 59: 6�3�- Primary Current

    CVM-C11 6�3�- PRIMARY CURRENT Note: Parameter not available in model CVM-C11-FLEX-IN-485-ICT2. The current transformer primary is programmed on this screen. Press key for 3 seconds to edit the value. The icon appears at the top of the screen. To enter or modify the value, press the key repeatedly, increasing the value of the flashing digit.

  • Page 60: 6�5�- Primary Neutral Current

    Possible values Press key to access the next programming step. 6�5�- PRIMARY NEUTRAL CURRENT Note: Parameter not available in model CVM-C11-FLEX-IN-485-ICT2. The neutral current transformer primary is programmed on this screen. Press key for 3 seconds to edit the value. The icon appears at the top of the screen.

  • Page 61: 6�6�- Secondary Neutral Current (Cvm-C11-Itf-In-Xxx-Ict2 Model)

    CVM-C11 6�6�- SECONDARY NEUTRAL CURRENT (CVM-C11-ITF-IN-xxx-ICT2 Model) The neutral current transformer secondary is programmed on this screen. Press key for 3 seconds to edit the value. The icon appears at the top of the screen. The key jumps between the possible options.

  • Page 62: 6�8�- Measurement Convention

    3 seconds and the icon will disappear from the display. Configuration values Table 29:Configuration values: Measurement convention� Measurement convention Cir Circutor measurement convention. Possible values IEC IEC 61557-12 measurement convention. IEEE IEEE 1459 measurement convention. Press key to access the next programming step.

  • Page 63: 6�9�- Type Of Installation

    CVM-C11 6�9�- TYPE OF INSTALLATION The type of installation is selected on this screen. Press key for 3 seconds to edit the value. The icon appears at the top of the screen. The key jumps between the possible options. To validate the data, press for 3 seconds and the icon will disappear from the display.

  • Page 64: 6�11�- Maximum Demand Integration Period

    CVM-C11 Press key for 3 seconds to edit the value. The icon appears at the top of the screen. The key jumps between the possible options. To validate the data, press for 3 seconds and the icon will disappear from the display.

  • Page 65: 6�12�- Deleting Maximum Demand

    CVM-C11 Note: Programming the value 0 disables the calculation of the maximum demand. Note: When modifying the integration period, the device restarts the calculation of the maximum demand. Press key to access the next programming step. 6�12�- DELETING MAXIMUM DEMAND On this screen you select whether or not to delete the maximum demand.

  • Page 66: 6�14�- Selecting The Operation Profile

    CVM-C11 To validate the data, press for 3 seconds and the icon will disappear from the display. Configuration values Table 34:Configuration values: THD calculation� THD calculation thd Calculation using the effective value (RMS). Possible values THd Calculation using the fundamental value.

  • Page 67: 6�14�2�- Selecting The Screens

    CVM-C11 Press key for 3 seconds to edit the value. The icon appears at the top of the screen. The key jumps between the possible options. To validate the data, press for 3 seconds and the icon will disappear from the display.

  • Page 68: 6�15�- Backlight, Turning On The Backlit Display

    CVM-C11 Configuration values Table 37:Configuration values: Selecting the screens� Selecting the screens Yes, to display the screen in the user menu. Possible values No, to stop displaying the screen. Press key to access the next programming step. This programming step is repeated for each one of the 19 screens of the device.

  • Page 69: 6�16�- Display Selection Cos Φ - Pf

    CVM-C11 6�16�- DISPLAY SELECTION cos φ - PF , the Cos or the PF, In this screen it is selected what is going to be visualized in the icon, φ power factor� Press key for 3 seconds to edit the value. The icon appears at the top of the screen.

  • Page 70: 6�18�- Deleting Energy Values

    CVM-C11 Configuration values Table 40:Configuration values: Deleting maximum and minimum values� Deleting maximum and minimum values Possible values Press key to access the next programming step. 6�18�- DELETING ENERGY VALUES On this screen you select whether or not to delete the energy values.

  • Page 71: 6�19�- Selecting The Range Of Energies

    CVM-C11 6�19�- SELECTING THE RANGE OF ENERGIES The operation of the range of energy is selected on this screen. Press key for 3 seconds to edit the value. The icon appears at the top of the screen. The key jumps between the possible options.

  • Page 72: Carbon Emission Ratio Of Consumed Energy

    CVM-C11 To validate the data, press for 3 seconds and the icon will disappear from the display. Configuration values Table 43:Configuration values: Harmonics display� Harmonics display Possible values Press key to access the next programming step. 6�21�- kgC0 CARBON EMISSION RATIO OF CONSUMED ENERGY The carbon emissions ratio is the amount of emissions released into the atmosphere to produce a unit of electricity (1 kWh).

  • Page 73: 6�22�- Kgc0 2 Carbon Emission Ratio Of Generated Energy

    CVM-C11 6�22�- kgC0 CARBON EMISSION RATIO OF GENERATED ENERGY The carbon emissions ratio is the amount of emissions released into the atmosphere to produce a unit of electricity (1 kWh). The ratio for the European mix is approximately 0.65 kgCO per kWh.

  • Page 74: 6�23�- Cost Ratio Of Consumed Energy

    CVM-C11 6�23�- COST RATIO OF CONSUMED ENERGY The cost per kWh of electricity of the three tariffs of the device is calculated on this screen. Press key for 3 seconds to edit the value. The icon appears at the top of the screen.

  • Page 75: 6�25�- Programming The Alarm Relay 1

    CVM-C11 When the desired value is shown on the screen, move onto the next digit by pressing the key modify the other values. Press key to browse the different tariffs. To validate the data, press for 3 seconds and the icon will disappear from the display.
  • Page 76 CVM-C11 Table 48: Parameter codes used to program the outputs� Parameter Phase Code Phase Code Phase Code Phase Code Phase-Neutral Voltage Current Active power Inductive Reactive Power Capacitive Reactive Power Apparent power Power factor Cosine φ % THD V % THD A...

  • Page 77: 6�25�1�- Maximum Value

    CVM-C11 6�25�1�- MAXIMUM VALUE On this screen, the value above which the alarm is activated is programmed. Press key for 3 seconds to edit the value. The icon appears at the top of the screen. To enter or modify the value, press the key repeatedly, increasing the value of the flashing digit.

  • Page 78: 6�25�2�- Minimum Value

    CVM-C11 Press key to access the next programming step. 6�25�2�- MINIMUM VALUE On this screen, the value below which the alarm is activated is programmed. Press key for 3 seconds to edit the value. The icon appears at the top of the screen.

  • Page 79: 6�25�4�- Hysteresis Value

    CVM-C11 Press key for 3 seconds to edit the value. The icon appears at the top of the screen. To enter or modify the value, press the key repeatedly, increasing the value of the flashing digit. When the desired value is shown on the screen, move onto the next digit by pressing the key modify the other values.

  • Page 80: 6�25�5�- Latch

    CVM-C11 6�25�5�- LATCH The latch is selected on this screen, i.e., if the alarm is interlocked after it has been tripped, even when the condition that triggered it has disappeared. Press key for 3 seconds to edit the value. The icon appears at the top of the screen.

  • Page 81: 6�25�7�- Contact Status

    CVM-C11 Configuration values Table 54:Configuration values: Disconnection delay� Disconnection delay Minimum value 0 seconds Maximum value 9999 seconds Press key to access the next programming step. 6�25�7�- CONTACT STATUS The status of relay contacts is selected on this screen. Press key for 3 seconds to edit the value.

  • Page 82: 6�27�- Programming Alarm 3 (Digital Output T1)

    CVM-C11 6�27�- PROGRAMMING ALARM 3 (DIGITAL OUTPUT T1) All values for digital output T1 are programmed on this screen. The variable code is selected on this screen, depending on which will Table 48, Table 49 Table 56, control digital output T1.

  • Page 83: 6�27�1�- Kilowatts Per Pulse

    CVM-C11 If you have selected a parameter from the subsequent programming steps are: Table 56, 6�27�1�- KILOWATTS PER PULSE In this section, the kilowatts per pulse of digital output T1 are programmed. Press key for 3 seconds to edit the value. The icon appears at the top of the screen.

  • Page 84: 6�27�2�- Pulse Width

    CVM-C11 6�27�2�- PULSE WIDTH The width of the pulse is selected on this screen in ms. Press key for 3 seconds to edit the value. The icon appears at the top of the screen. To enter or modify the value, press the key repeatedly, increasing the value of the flashing digit.

  • Page 85: 6�29�- Operating Mode Of Digital Input 1

    CVM-C11 6�29�- OPERATING MODE OF DIGITAL INPUT 1 The function of digital input 1 is selected on this screen. Press key for 3 seconds to edit the value. The icon appears at the top of the screen. The key jumps between the possible options.

  • Page 86: 6�31�- Rs-485 Communications: Protocol

    Table 61:Configuration values: RS-485: Protocol� RS-485: Protocol Modbus Possible values BACnet Not available for model CVM-C11-ITF-IN-ETH-ICT2� Note: The device will restart after exiting the setup menu if the RS-485 communications parameters have been modified. Press key to access the next programming step.

  • Page 87: 6�32�- Modbus Protocol: Baud Rate

    CVM-C11 6�32�- MODBUS PROTOCOL: BAUD RATE Note: Screen visible if the Modbus protocol has been programmed, “6.31.- RS-485 COMMUNICATIONS: � PROTOCOL” The baud rate of Modbus communications is programmed on this screen. Press key for 3 seconds to edit the value. The icon appears at the top of the screen.

  • Page 88: 6�34�- Modbus Protocol: Parity

    CVM-C11 When the desired value is shown on the screen, move onto the next digit by pressing the key modify the other values. The programmed value will be deleted if the entered value is higher than the maximum programming value.

  • Page 89: 6�35�- Modbus Protocol: Number Of Data Bits

    CVM-C11 6�35�- MODBUS PROTOCOL: NUMBER OF DATA BITS Note: Screen visible if the Modbus protocol has been programmed, “6.31.- RS-485 COMMUNICATIONS: � PROTOCOL” The number of data bits of Modbus communications are programmed on this screen. Note: This parameter cannot be modified.

  • Page 90: 6�37�- Bacnet Protocol: Baud Rate

    CVM-C11 6�37�- BACnet PROTOCOL: BAUD RATE Note: Not available for model CVM-C11-ITF-IN-ETH-ICT2� Note: Screen visible if the BACnet protocol has been programmed, “6.31.- RS-485 COMMUNICATIONS: � PROTOCOL” The baud rate of BACnet communications is programmed on this screen. Press key for 3 seconds to edit the value.

  • Page 91: 6�39�- Bacnet Protocol: Mac Address

    Maximum value 999999 Press key to access the next programming step. 6�39�- BACnet PROTOCOL: MAC ADDRESS Note: Not available for model CVM-C11-ITF-IN-ETH-ICT2� Note: Screen visible if the BACnet protocol has been programmed, “6.31.- RS-485 COMMUNICATIONS: � PROTOCOL” The MAC address is programmed on this screen.

  • Page 92: 6�40�- Locking The Programming

    CVM-C11 Configuration values Table 68:Configuration values: BACnet, MAC address� BACnet: MAC address Minimum value Maximum value Press key to access the next programming step. 6�40�- LOCKING THE PROGRAMMING This screen is for protecting the data configured in the programming menu.
  • Page 93 CVM-C11 Press key for 3 seconds to edit the value. The icon appears at the top of the screen. To enter or modify the value, press the key repeatedly, increasing the value of the flashing digit. When the desired value is shown on the screen, move onto the next digit by pressing the key modify the other values.

  • Page 94: 7�- Configuration Of Ethernet Communications

    CVM-C11 7.- CONFIGURATION OF ETHERNET COMMUNICATIONS Note: Ethernet communications are available on model CVM-C11-ITF-IN-ETH-ICT2. To enter the configuration menu you must press the keys for 3 seconds. To exit the configuration menu, press the key for 3 seconds. If a reset is performed before validation or no key is pressed for 30 seconds, the configuration made is not stored in memory.

  • Page 95: 7�2�- Modbus Tcp Protocol: Dhcp

    CVM-C11 7�2�- MODBUS TCP PROTOCOL: DHCP Note: Screen visible if the Modbus TCP protocol has been programmed, “7.1.- PROTOCOL”. On this screen you select whether or not to enable DHCP. If DHCP enable is selected (default setting), the IP address is assigned dynamically through a central server and no further parameters need to be configured.

  • Page 96: 7�4�- Modbus Tcp Protocol: Mask

    CVM-C11 Press key for 3 seconds to edit the value. The icon appears at the top of the screen. To enter or modify the value, press the key repeatedly, increasing the value of the flashing digit. When the desired value is shown on the screen, move onto the next digit by pressing the key modify the other values.

  • Page 97: 7�5�- Modbus Tcp Protocol: Gateway

    CVM-C11 7�5�- MODBUS TCP PROTOCOL: GATEWAY Note: Screen visible if the Modbus TCP protocol has been programmed, “7.1.- PROTOCOL”. This screen configures (DHCP not enabled) or displays the gateway for Ethernet communications. Press the key to display the value. Press key for 3 seconds to edit the value.

  • Page 98: 7�7�- Modbus Tcp Protocol: Port

    CVM-C11 7�7�- MODBUS TCP PROTOCOL: PORT Note: Screen visible if the Modbus TCP protocol has been programmed, “7.1.- PROTOCOL”. The Ethernet communications port is configured on this screen. Press key for 3 seconds to edit the value. The icon appears at the top of the screen.

  • Page 99: 8�- Rs-485 Communications

    CVM-C11 8.- RS-485 COMMUNICATIONS The CVM-C11 devices have one RS-485 communications port. The device has as standard two communications protocols: MODBUS RTU ® and BACnet. The protocol and configuration parameters are selected in the setup menu. ( “6.31. RS-485 COMMUNI- CATIONS: PROTOCOL”...

  • Page 100: 8�2�- Modbus Protocol

    CVM-C11 8�2�- MODBUS PROTOCOL In the Modbus protocol, the CVM-C11 device uses the RTU (Remote Terminal Unit) mode. The Modbus functions implemented in the device are as follows: Function 0x01: Reading a relay. Function 0x02: Reading a digital input. Function 0x03 and 0x04: Reading integer logs.

  • Page 101: 8�3�- Modbus Commands

    CVM-C11 CRC: CEEF, CRC character. Response: Initial Address Function Value Register 0834 FF00 CEEF 8�3�- MODBUS COMMANDS All the addresses of Modbus memory are in Hexadecimal. 8�3�1�- MEASUREMENT VARIABLES For these variables is implemented the Function 0x03 and 0x04� Table 73: Modbus memory map (Table 1)

  • Page 102: 8�3�2�- Energy Variables

    CVM-C11 Table 73 (Continuation): Modbus memory map (Table 1) Parameter Symbol Instantaneous Maximum Minimum Units Three-phase Cos φ Cos φ III 3A-3B 140-141 19E-19F x100 L1 Frequency 3C-3D 142-143 1A0-1A1 Hz x100 L1-L2 Voltage 3E-3F 144-145 1A2-1A3 V x 10...

  • Page 103: 8�3�3�- Voltage And Current Harmonics

    CVM-C11 Table 74 (Continuation): Modbus memory map (Table 2) Parameter Symbol Tariff 1 Tariff 2 Tariff 3 Total Units Generated CO emissions KgCO 82-83 AC-AD D6-D7 100-101 Generation Cost 84-85 AE-AF D8-D9 102-103 Hours per tariff Hours 86-87 B0-B1 DA-DB 104-105 8�3�3�- VOLTAGE AND CURRENT HARMONICS...

  • Page 104: 8�3�4�- Deleting Parameters

    CVM-C11 Table 76: Modbus memory map (Table 4)� Parameter L1 Current L2 Current L3 Current Units Fundamental Harm. A88-A89 AA8-AA9 AC8-AC9 2nd Order harmonic % x 10 3rd Order harmonic % x 10 4th Order harmonic % x 10 5th Order harmonic...

  • Page 105: 8�3�5�- Power Status

    CVM-C11 8�3�5�- POWER STATUS The Function 0x04 is implemented for this variable. This variable indicates the quadrant in which the device is operating. Table 78: Modbus memory map: Power status Power status Variable Address Default value Power status The variable format is shown in Table 79: Table 79: Variable format: Power status�...

  • Page 106: 8�3�9�- Device Configuration Variables

    All variables must be programmed at the same time. (10) Voltage ratio x Current ratio < 600000. (11) Parameter not available in model CVM-C11-FLEX-IN-485-ICT2. (12) Only available for models CVM-C11-ITF-IN-xxx-ICT2� (13) Note: The ratio is between the primary and the secondary.
  • Page 107 CVM-C11 8�3�9�3�- Number of quadrants Table 86: Modbus memory map: Number of quadrants Maximum demand Default Configuration variable Address Valid data margin value 0: 4 quadrants Number of quadrants 2B64 1: 2 quadrants 8�3�9�4� Measurement convention Table 87: Modbus memory map: Measurement convention�...
  • Page 108 CVM-C11 8�3�9�8�- Operating profile Table 91: Modbus memory map: Operating profile Operating profile Default Configuration variable Address Valid data margin value 0: Analyzer 1: User Operating profile 2B60 2: Electrical energy efficiency, e 8�3�9�9�- Display backlight Table 92: Modbus memory map: Backlight...
  • Page 109 CVM-C11 All variables must be programmed at the same time. (21) They have 4 decimal place. (22) 8�3�9�13�- Programming alarms 1 and 2 (Relays 1 and 2) Table 96: Modbus memory map: Programming alarms 1 and 2� Programming alarms 1 and 2...
  • Page 110 (26) 0 : 1 stop bit Modbus: Stop bits 2747 1: 2 stop bits BACnet: Device ID 2EE0- 2EE1 0- 999999 BAcnet: MAC 2EE2 0- 255 Not available for model CVM-C11-ITF-IN-ETH-ICT2. (25) This parameter cannot be modified. (26) Instruction Manual...

  • Page 111: 8�4�- Bacnet Protocol

    You must program all the variables at the same time. (27) The password value is read and written in hexadecimal. (28) 8�3�9�19�- Ethernet Communications Note: Ethernet communications are available on model CVM-C11-ITF-IN-ETH-ICT2. Table 105: Modbus memory map: Ethernet communications� Ethernet communications Configuration variable Address...

  • Page 112: 8�4�1�- Mapa Pics

    CVM-C11 Using a RS485 connection, the device can connect to a BACnet and include all of the objects and services defined in the attached PICS map (Protocol Implementation Conformance Statement). ( “7.4.1. PICS MAP”) The default speed is 9600 bps and the MAC is 2 (node number), and can be changed on the configuration screen or by entering the BaudRate and MAC_Address variables.
  • Page 113 CVM-C11 5. List of proprietary properties: 6. List of any property value range restrictions: Properly Identifier Object_Name max 32 characters DESCRIPTION SYMBOL ID OBJECTS OBJECT NAME UNITS Tensión fase-neutro Voltage phase to neutral Ph2NU1 Corriente Current Ph1Current Potencia activa Active power...
  • Page 114 CVM-C11 DESCRIPTION SYMBOL ID OBJECTS OBJECT NAME UNITS Energía inductiva gene- Three phase generated kvarL•h III (-) AI35 IndEnergy_exp kvarL•h rada reactive inductive energy Three phase genera- Energía capacitiva ge- ted reactive capacitive kvarC•h III(-) AI36 CapEnergy_exp kvarC•h nerada energy Energía aparente gene-...
  • Page 115 CVM-C11 Object_Identifier Device Type only Number_Of_APDU_Retries 0-255 APDU_Timeout 0-65535 miliseconds Vendor_Identifier 0-65535 Data Link Layer Options (check all that supported): MS/TP master (Clause 9), baud rate(s): 9.6, 19.2kB/s Character Sets Supported (check all that apply): Indicating support for multiple character set does not imply that they can all be supported simultaneously.

  • Page 116: 9�- Technical Features

    CVM-C11 9.- TECHNICAL FEATURES AC Power supply Rated voltage 100 ... 270 V ± 10% 50 ... 60 Hz Frequency CVM-C11-ITF-IN-485 CVM-C11-ITF-IN-ETH CVM-C11-FLEX-IN-485 CVM-C11-MC-IN-485 Consumption 2 ... 5 VA 2 ... 7 VA 2.5 ... 5.5 VA 2.5 ... 5.5 VA...
  • Page 117 CVM-C11 Measurement accuracy (UNE-EN 61557-12) (31) CVM-C11-ITF-IN-xxx cos φ Power factor CVM-C11-FLEX-IN-485 (without sensors MFC-FLEX) Voltage measurement 0.2 % Current measurement 0.2 % (5 ... 120 % In) Frequency measurement 0.025 Hz Active power measurement 0.5 % Reactive power measurement Apparent power measurement 0.5 %...
  • Page 118 9600 - 19200 - 38400 bps Stop bits 1 - 2 Parity without - even - odd without (32) Not available for model CVM-C11-ITF-IN-ETH-ICT2. Ethernet communication (CVM-C11-ITF-IN-ETH-ICT2) Type Ethernet 10BaseT - 100BaseTX self-detectable Connector RJ45 Protocol Modbus TCP - BACnet IP...
  • Page 119 Electrical safety in low voltage distribution systems up to 1 000 V AC and 1 500 V DC - Equipment for testing, measuring or monitoring of protective measures - Part 12: EN IEC 61557-12 Power metering and monitoring devices (PMD) Figure 41: Dimensions of the CVM-C11� Instruction Manual...

  • Page 120: 10�- Maintenance And Technical Service

    CVM-C11 10.- MAINTENANCE AND TECHNICAL SERVICE In the case of any query in relation to device operation or malfunction, please contact the CIRCUTOR S�A�U� Technical Support Service. Technical Assistance Service Vial Sant Jordi, s/n, 08232 - Viladecavalls (Barcelona) Tel: 902 449 459 (Spain) / +34 937 452 919 (outside of Spain) email: sat@circutor.com...

  • Page 121: 12�- Eu Declaration Of Conformity

    CVM-C11 12.- EU DECLARATION OF CONFORMITY Instruction Manual...
  • Page 122 CVM-C11 Instruction Manual...
  • Page 123 CVM-C11 Instruction Manual...

  • Page 124: Annex A.- Configuration Menus

    Secondary neutral   current 3 s. 3 s.   Number of quadrants (33) Only available on CVM-C11-ITF-IN-xxx-ICT2 models.  3 s. 3 s. (34) Parameter not available in model. CVM-C11-FLEX-IN-485-ICT2. Measurement   convention Instruction Manual   ...
  • Page 125 CVM-C11 3 s. 3 s.   Number of quadrants  3 s. 3 s. Measurement   convention    3 s. 3 s. Type of installation  (35)    3 s. 3 s. Type of integration of the ...
  • Page 126 CVM-C11 3 s. 3 s. Deleting maximum and   minimum values 3 s. 3 s. Deleting energy values   3 s. 3 s. Selecting the Range of   energies 3 s. 3 s. Activating the harmonics ...
  • Page 127 CVM-C11 3 s. 3 s. Programming alarm 3 (Digital output T1) A.3.- 3 s. 3 s. Programming alarm 4 (Digital output T2) A.3.-  3 s. 3 s. Operating mode of digital ue  input 1 3 s. 3 s.

  • Page 128: Annex A�1�- Selecting The Operation Profile

    CVM-C11 ANNEX A�1�- SELECTING THE OPERATION PROFILE Selecting the operation profile  3 s. 3 s. Selecting the operation   profile  3 s. 3 s. Selecting the screens that   will be displayed  3 s. 3 s.

  • Page 129: Annex A�2�- Programming The Alarm Relay 1 Amd 2

    CVM-C11 ANNEX A�2�- PROGRAMMING THE ALARM RELAY 1 AMD 2 Programming the alarm relay 1 and 2 3 s. 3 s.   3 s. 3 s. Variable code         3 s. 3 s.

  • Page 130: Annex A�3�- Programming Alarm 3 And 4

    CVM-C11 ANNEX A�3�- PROGRAMMING ALARM 3 AND 4 Programming Alarm 3 (Digital output T1) and Alarm 4 (Digital output T2) 3 s.  3 s. Variable code     3 s.  3 s. kilowatts per  ...

  • Page 131: Annex A�4�- Rs-485 Communications Programming

    Baud rate   3 s. 3 s.  3 s. Device ID     3 s.  3 s. MAC address     Note: RS-485 BACNet communications are not available for the CVM-C11-ITF-IN-ETH-ICT2 model. Instruction Manual...

  • Page 132: Annex A�5�- Locking The Programming

    CVM-C11 ANNEX A�5�- LOCKING THE PROGRAMMING Locking the programming 3 s. 3 s. Locking the unloc  programming  3 s.  3 s.    Password  Instruction Manual...

  • Page 133: Annex B.- Ethernet Configuration Menus

    CVM-C11 ANNEX B.- ETHERNET CONFIGURATION MENUS Note: Ethernet communications are available on model CVM-C11-ITF-IN-ETH-ICT2. Ethernet configuration menu 3 s. 3 s. 3 s. Modbus TCP Protocol BACnet 3 s. 3 s.   DHCP 3 s. 3 s.  IP Adress ...
  • Page 134 CIRCUTOR S.A.U. Vial Sant Jordi, s/n 08232 -Viladecavalls (Barcelona) Tel.: (+34) 93 745 29 00 - Fax: (+34) 93 745 29 14 www.circutor.com central@circutor.com...

Table of Contents

Save PDF
