6�2�- Secondary Voltage - Circutor CVM-C11 Instruction Manual

Voltage ratio x Primary Current < 600000
Note: The ratio is the relation between the primary and the secondary.
Press key
6�2�- SECONDARY VOLTAGE
On this screen the voltage transformer secondary is programmed.
Press key
To enter or modify the value, press the
When the desired value is shown on the screen, move onto the next digit by pressing the key
modify the other values.
To validate the data, press
The programmed value will be deleted if the entered value is higher than the maximum programming
value.
Configuration values
Press key
58
to access the next programming step.
for 3 seconds to edit the value. The
for 3 seconds and the
Table 23:Configuration values: Secondary voltage�
Minimum value
Maximum value
to access the next programming step.
icon appears at the top of the screen.
key repeatedly, increasing the value of the flashing digit.
icon will disappear from the display.
Secondary voltage
1
999
CVM-C11
to
Instruction Manual
