6�1�- Primary Voltage - Circutor CVM-C11 Instruction Manual

CVM-C11
To access the first programming step, press the
The programming parameters are validated as follows:
 When on reaching the last point on the programming menu ("
") the key is pressed
MING
 At any point in the programming, by pressing the key
If the device is reset before validation or no key is pressed for 30 seconds, the configuration will not
be stored in the memory.
To exit the configuration menu, press the
Note: In the annex
"ANNEX A.- CONFIGURATION MENUS"
6�1�- PRIMARY VOLTAGE
On this screen the voltage transformer primary is programmed.
Press key for 3 seconds to edit the transformer primary value. The
of the screen.
To enter or modify the value, press the
When the desired value is shown on the screen, move onto the next digit by pressing the key
modify the other values.
To validate the data, press
The programmed value will be deleted if the entered value is higher than the maximum programming
value.
Configuration values
Instruction Manual
key.
.
key for 3 seconds.
key repeatedly, increasing the value of the flashing digit.
for 3 seconds and the
Table 22:Configuration values: Primary voltage�
Primary voltage
Minimum value
Maximum value
6.40.- LOCKING THE PROGRAM-
for 3 seconds.
you can see the configuration tree.
icon appears at the top
icon will disappear from the display.
1
599999
to
57
