Circutor CVM-C11 Instruction Manual page 118

Quantity
Type
Maximum voltage
Maximum current
Maximum frequency
Pulse width
Bus
Protocol
Baud rate
Stop bits
Parity
(32)
Not available for model CVM-C11-ITF-IN-ETH-ICT2.
Type
Connector
Protocol
Connection mode to Network
Display
Keyboard
LED
Operating temperature
Storage temperature
Relative humidity (non-condensing)
Maximum altitude
Protection degree IP
Protection degree IK
Pollution degree
Use
Terminals
1, 2, 14 ... 17, 9 ... 13, 18 ... 25
3 ... 8
Dimensions ( Figure 41)
Weight
Surround
Attachment
118
Digital outputs
Communications
Modbus RTU
RS-485
Modbus RTU
without - even - odd
Ethernet communication (CVM-C11-ITF-IN-ETH-ICT2)
User interface
Environmental features
Mechanical features
0.2 ... 2.5 mm
0.2 ... 1.5 mm
CVM-C11-ITF-IN-xxx
353 g.
2
NPN
24 V
50 mA
16 impulses / sec
300 ms to 400 ms
9600 - 19200 - 38400 bps
1 - 2
Ethernet 10BaseT - 100BaseTX self-detectable
RJ45
Modbus TCP - BACnet IP
DHCP ON/OFF (ON by default)
LCD Custom COG
3 keys
2 LED
-25ºC ... +70ºC
-25ºC ... +75ºC
5 ... 95%
2000 m
IP20, Front panel: IP54
IK08
2
Indoor
0.5 ... 0.6 Nm
2
0.2 ... 0.25 Nm
2
96 x 96 x 67.2 mm
CVM-C11-MC-IN-485
317 g.
Self-extinguishing V0 plastic
Panel
CVM-C11
BACnet
(32)
MS/TP
BACnet
1
without
M3
M2
CVM-C11-FLEX-IN-485
300 g.
Instruction Manual
