6�25�5�- LATCH
The latch is selected on this screen, i.e., if the alarm is interlocked after it has been tripped, even when
the condition that triggered it has disappeared.
Press key
The key
To validate the data, press
Configuration values
Note: If the device is reset, the status of alarms is deleted and all alarms will return to the programmed
standby status, provided that the condition that triggered them has been resolved.
Press key
6�25�6�- DISCONNECTION DELAY
The alarm disconnection delay is programmed on this screen in seconds.
Press key
To enter or modify the value, press the
When the desired value is shown on the screen, move onto the next digit by pressing the key
modify the other values.
To validate the data, press
80
for 3 seconds to edit the value. The
jumps between the possible options.
for 3 seconds and the
Table 53:Configuration values: Latch�
Possible values
to access the next programming step.
for 3 seconds to edit the value. The
for 3 seconds and the
icon appears at the top of the screen.
icon will disappear from the display.
Latch
Yes
No
icon appears at the top of the screen.
key repeatedly, increasing the value of the flashing digit.
icon will disappear from the display.
