CVM-C11
3�4�3�- CVM-C11-FLEX-IN-485-ICT2 MODEL
1
1 : A1(+), Power supply
2 : A2(-), Power supply
3 : ROC, Common relay output
4 : RO1, Relay output 1
5 : RO2, Relay output 2
6 : DOC, Common digital outputs
7 : DO1, Digital output 1
8 : DO2, Digital output 2
9 : DIC, Common digital inputs
10 : DI1, Digital input 1
11 : DI2, Digital input 2
12 : A(+), RS-485
Instruction Manual
2 4
3 5 6
POWER SUPPLY OUTPUTS
A2(-)
A1(+) R0C R01 R02 D0C D01 D02
U
U U
L1
L3 L2
U U U N
L1 L2 L3
14 15 16 17 18 19 20 21
Figure 3: CVM-C11-FLEX-IN-485-ICT2 terminals�
Table 6: List of terminals of the CVM-C11-FLEX-IN-485-ICT2�
Device terminals
13 : B(-), RS-485
14 : U
15 : U
16 : U
17 : N, Neutral / U
18 : IL1 (OUT+), Current input L1
19 : IL2 (OUT+), Current input L2
20 : IL3 (OUT+), Current input L3
21 : IN (OUT+), Current input N
22 : OUT-, common of current inputs
23 : SHLD, GND of current inputs
7 8 10 11 12
9
INPUTS RS-485
A(+) B(-)
DIC DI1 DI2
OUT+ OUT- SHLD
IL3 IN
IL1 IL2
22 23
Voltage input L1
L1,
Voltage input L2
L2,
Voltage input L3
L3,
Voltage input L2
L2,
