CVM-C11
6�6�- SECONDARY NEUTRAL CURRENT (CVM-C11-ITF-IN-xxx-ICT2 Model)
The neutral current transformer secondary is programmed on this screen.
Press key for 3 seconds to edit the value. The
The key jumps between the possible options.
To validate the data, press
Configuration values
Press key to access the next programming step.
6�7�- NUMBER OF QUADRANTS
The quadrant number on which the device takes the measurement is selected on this screen.
Press key for 3 seconds to edit the value. The
The key jumps between the possible options.
To validate the data, press
Instruction Manual
for 3 seconds and the
Table 27:Configuration values: Secondary neutral current�
Secondary neutral current
Possible values
for 3 seconds and the
icon appears at the top of the screen.
icon will disappear from the display.
1 A
5 A
icon appears at the top of the screen.
icon will disappear from the display.
61
