CVM-C11
 The data area, which displays all the values measured by the device.
The units and status area, which displays the different statuses, units and device information
( ).
Table 15
Icon
Analyzer profile.
Electrical
profile, e
3
User profile.
Maximum demand.
Maximum value.
Minimum value.
Configuration menu protected
by password.
Screen in edit mode in the con-
figuration menu.
Active RS-485 communica-
tions.
4�2�1�- cos
φ - PF (POWER FACTOR)
This bar displays the value of the installation's cos
that will be displayed is selected on the programming menu. (
4�2�2�- ANALOGUE BAR
The current power of the installation in % is displayed on the analog bar. When the value exceeds
110% the analog bar flashes. And if the value exceeds 999% -Hiis displayed.
Instruction Manual
Table 15:Display icons�
Description
energy efficiency
.
Figure 31: Cos φ - PF�
Figure 32: Analogue Bar
Icon
Analog bar, where the % of the current
power of the installation is shown.
Quadrant in which the device is working.
cos φ or the power factor of the instal-
lation.
Consumption.
Generation.
Digital input connected.
Relay disconnected or connected.
Digital output connected.
T1, T2, T3 Active tariff.
or Power Factor (PF) in real time. The parameter
φ
"6.16.- DISPLAY SELECTING Cos φ - PF"
Description
).
43
