6�19�- SELECTING THE RANGE OF ENERGIES
The operation of the range of energy is selected on this screen.
Press key for 3 seconds to edit the value. The
The key jumps between the possible options.
To validate the data, press
Configuration values
Possible values
Press key to access the next programming step.
To validate the change in the energy range, it is necessary to delete the energy values
(
"6.18.-DELETING ENERGY VALUES"
6�20�- ACTIVATING THE HARMONICS DISPLAY SCREEN
This screen is used to select whether harmonics are displayed or not.
Press key for 3 seconds to edit the value. The
The key jumps between the possible options.
Instruction Manual
for 3 seconds and the
Table 42:Configuration values: Selecting the range of energies�
Selecting the range of energies
AUTO The device displays the kWh and MWh. When the energy value
reaches 999999kWh, the device automatically selects the MWh range.
ShoRT The device only displays the KWh. When the energy value reaches
999999kWh, the device resets the measurement to 0kWh.
).
icon appears at the top of the screen.
icon will disappear from the display.
icon appears at the top of the screen.
