6.1.- PRIMARY VOLTAGE
On this screen the voltage transformer primary is programmed.
Press the
of the screen.
Press the
When the desired value is shown on the screen, use the
cursor.
To validate the value, press the
If the value entered by the user is out of the range of programming values, the programmed
value will be deleted and the system will restore it to the last saved value.
Maximum programming value: 99999.
Minimum programming value: 1.
Voltage ratio ≤ 1000.
Voltage ratio x Current ratio ≤ 300000.
Note: The ratio is the relation between the primary and the secondary.
Press key
6.2.- SECONDARY VOLTAGE
On this screen the voltage transformer secondary is programmed.
Press the
of the screen.
Press the
56
key for 3 seconds to enter the edit mode. The prog icon will flash on the left
key to modify the value of the flashing digit.
to access the next programming step.
key for 3 seconds to enter the edit mode. The prog icon will flash on the left
key to modify the value of the flashing digit.
key for 3 seconds; the prog icon will stop flashing.
CVM-E3-MINI
and keys to move the edit
