Electrical Schematic Component Identification

Electrical components shown in the main schematic are identified with an alphanumeric call out. All electrical
components shown in the electrical schematic are listed below.
• B1—12V Battery (See Figure 4-4.)
• B2—12V Battery (See Figure 4-4.)
• B3—12V Battery (See Figure 4-4.)
• B4—12V Battery (See Figure 4-4.)
• E1—Spark Plug (See Figure 4-4.)
• F1—50A Fuse (See Figure 4-4.)
• F2—30A Fuse (See Figure 4-4.)
• M1—Reel Motor (See Figure 4-5.)
• M2—Traction Motor (See Figure 4-5.)
• R1—Throttle Potentiometer (See Figure 4-4.)
• R2—Bail Potentiometer (See Figure 4-4.)
• R3—5-Ohm Resistor (See Figure 4-4.)
• SW1—Mow Switch (See Figure 4-4.)
• SW2—Key Switch (See Figure 4-4.)
4
• SW3—Engine On/Off Switch (See Figure 4-4.)
• SW4—Light Switch (See Figure 4-5.)
• T1—Ignition CoIl (See Figure 4-4.)
• U1—Reel Motor Controller (See Figure 4-5.)
• U2—Traction Motor Controller (See Figure 4-5.)
• U3—1kW Generator (See Figure 4-4.)
• U4—Battery Gauge (See Figure 4-4.)
• U5—Main Control Unit (MCU) (See Figure 4-4.)
