Cutting Unit
Check and Adjustment Specifications
Bedknife-to-Reel Gap
Reel Bearing Pre-Load
Bedknife Front Face Height (minimum)
Bedknife Front Face Angle (all bedknives)
Bedknife Top Face Angle (rear relief) (all bedknives
except Super Tournament)
Super Tournament Bedknife Top Face Angle
(rear relief)
Reel Blade Relief Angle
Accessories
Check and Adjustment Specifications
Turf Groomer Eccentric Mounting Screw Torque
Turf Groomer Belt Tension Link Mounting Screw Torque
Repair Specifications
Solid Front Roller Assembly Maximum Rotational
Resistance
Solid Tube Front Roller Lock Nut Torque
Solid Tube Front Roller Shaft-to-Bearing Rotational
Resistance
Solid Tube Front Roller Assembly Maximum Rotational
Resistance
Grooved Front Roller Lock Nut Torque
Grooved Front Roller Shaft-to-Bearing Rotational
Resistance
Grooved Front Roller Assembly Rotational Resistance
Grooved Disc Roller Assembly Maximum Rotational
Resistance
Grooved Segmented Front Roller Jam Nut Torque
Grooved Segmented Front Roller Assembly Rotational
Resistance
Push Broom Assembly Rod-To-Cam Gap
4262930-Rev A
SPECIFICATIONS AND GENERAL INFORMATION
in. (mm)
in. (mm)
in. (mm)
degrees
degrees
degrees
degrees
lb-ft (N·m)
lb-ft (N·m)
6 (0.68) Maximum with No End Play
lb-in. (N·m)
lb-ft (N·m)
0–1 (0–0.11) with No End Play
lb-in. (N·m)
6 (0.68) Maximum with No End Play
lb-in. (N·m)
lb-ft (N·m)
0–1 (0–0.11) with No End Play
lb-in. (N·m)
6 (0.68) Maximum with No End Play
lb-in. (N·m)
6 (0.68) Maximum with No End Play
lb-in. (N·m)
lb-ft (N·m)
6 (0.68) Maximum with No End Play
lb-in. (N·m)
in. (mm)
0.001–0.003 (0.025–0.075)
0.040 (1.0)
0.035 (0.9)
5
8–10
5–7
45
8–10 (10.8–13.6)
20 (27.1)
10–30 (13.5–40.6)
10–30 (13.5–40.6)
70 (95)
0.25 (6.3)
2
