Textron JACOBSEN Eclipse 2 Technical/Repair Manual page 209

Turf Groomer—Drive and Driven
Assemblies
Disassembly and Assembly
See Figure 10-30.
11
10
15
1 Carriage Bolt (2) 5 Knob Adjustment (2)
2 Cotter Pin (2) 6 Adjuster Bracket (2)
3 Flat Washer (4) 7 Stud (2)
4 Grease Fitting (2) 8 Nut (3)
4262930-Rev A
2
3
1
16
17
15
4
6
8
12
9
8
13
10
3
9 Flat Washer (4)
10 Lock Washer (4)
11 Screw (2)
12 Push Groomer Plate (2)
Figure 10-30
4
5
6
7
14
3
10
12
8
13
5
19
7
18
1
13 Flat Washer (4)
14 Lift Bracket
15 Pin (2)
16 Left Hand Drive Bracket
ACCESSORIES
8
9
10
11
17
3
2
17 Groomer Bracket (2)
18 Lift Bracket
19 Left Hand Driven Bracket
TN4530
10
10-23
