Turf Groomer—Roller Assembly
Disassembly and Assembly
See Figure 10-32.
1 Roller Tube
2 Jam Nut (2)
3 Lock Washer (2)
4262930-Rev A
1
4 Flat Washer (2) 7
5 Ball Bearing (2) 8
6 Nylos Ring (2) 9
Figure 10-32
2
4
3
5
6
7
8
Grease Seal (2) 10 Shaft
Snap Ring (2) 11 Set Screw (4)
Grease Fitting (2) 12 Nut (4)
ACCESSORIES
9
10
11
12
TN4532
10-25
10
