Textron JACOBSEN Eclipse 2 Technical/Repair Manual page 123

Installation
See Figures 5-35 through 5-39.
Required Materials
®
Loctite Aviation Gasket Sealer (Loctite PN 30516)
1
Figure 5-35
1. Install a new grease seal (1) in the seal cover (2).
3
4
Figure 5-36
2. Clean the mating surfaces of the seal cover (5) and
bearing housing (3), and apply a thin film of Loctite
Aviation Gasket Sealer to the surfaces.
3. Pack bearing (4) with grease that meets or exceeds
NLGI Grade 2 LB specifications before installation.
4262930-Rev A
6
2
TN0244
4. Install bearing and housing assembly (6).
5. Install locking collar (8) with the recessed side (9)
toward the bearing. Tighten the set screw (7).
5
TN0250
®
6. Install nut (10). Tighten until nut just contacts
bearing.
POWER TRAIN
8
9
Figure 5-37
Figure 5-38
7
TN0243, TN0240
5
10
TN0242
5-15
