Textron JACOBSEN Eclipse 2 Technical/Repair Manual page 148

CUTTING UNIT
Specifications
General Specifications
Height-of-Cut Range (Bench Setting)
High-Profile Cut Yield
Low-Profile Cut Yield
Tournament Cut Yield
Super Tournament Cut Yield
Championship Cut Yield
Reel Diameter
Reel Composition
Width of Cut
Check and Adjustment Specifications
Bedknife-to-Reel Gap
Reel Bearing Pre-Load
Bedknife Front Face Height (minimum)
Bedknife Front Face Angle (all bedknives)
Bedknife Top Face Angle (rear relief) (all bedknives
except Super Tournament)
Super Tournament Bedknife Top Face Angle
(rear relief)
Reel Blade Relief Angle
8
8-2
Specification
Specification
1/16–7/16 (1.6–11.1)
in. (mm)
5/32–7/16 (3.96)
in. (mm)
1/8–7/32 (3.17)
in. (mm)
3/32–5/32 (2.38)
in. (mm)
5/64–7/64 (1.58)
in. (mm)
1/16 –7/64 (1.58)
in. (mm)
in. (mm)
Hardened High-Manganese Carbon Steel
18 (457), 22 (557.5)
in. (cm)
0.001–0.003 (0.025–0.075)
in. (mm)
0.040 (1.0)
in. (mm)
0.035 (0.9)
in. (mm)
degrees
degrees
degrees
degrees
5 (127)
5
8–10
5–7
45
4262930-Rev A
