Instruction
Sheet
Turf Groomer™
1/4" Spacing
22" R.H. Groomer Product Number 67911
22" L.H. Groomer Product Number 67912
1/2" Spacing
22" R.H. Groomer Product Number 67913
22" L.H. Groomer Product Number 67914
18" R.H. Groomer Product Number 67926
If incorrectly used, this machine can cause severe injury. Those who use
and maintain this machine should be trained in its proper use, warned of its
dangers and should read the entire manual before attempting to set up,
operate, adjust, or service the machine.
WARNING
2812002
6
5
9
1 1
1 6
1 3
1 5
7
8
1 8
1 7
1 - I N C L U D E S I T E M S 3 - 1 6
1 9
3
1 0
4
When Performance Matters.
™
Advertisement
Related Manuals for Textron JACOBSEN Turf Groomer 67911
Summary of Contents for Textron JACOBSEN Turf Groomer 67911
- Page 1 2812002 1 - I N C L U D E S I T E M S 3 - 1 6 Instruction Sheet Turf Groomer™ 1/4” Spacing 22” R.H. Groomer Product Number 67911 22” L.H. Groomer Product Number 67912 1/2” Spacing 22”...
- Page 2 This product is used on 5.0” diameter reels on GKIV™, GKV™, G-Plex® and Fairway mowers. WARNING Before you clean, adjust, or repair this equipment, CAUTION disengage all drives, lower cutting units to the ground, engage parking brake, stop engine, remove key from Read the operator’s manual and become familiar with switch and disconnect Negative (BLACK) battery cable to the controls and proper use of the equipment.
- Page 3 1.2 PRE-ASSEMBLY _________________________________________________________________________________ 1. Remove 1/4” hardware (F) and cover / counterweight (G) 5. If you are installing the Turf Groomer on an LF series from non-motor end of reel. mower, move the height adjust pivot (N) from the bottom hole to the top hole of both driven assembly (A) and drive 2.
- Page 4 e. Slide pivot pin (Item 21) from pivot block (Item 11). From This: Reposition pivot block and loosely reassemble hardware (Items 24 & 10). The screw mounts through the inside flange of pivot block only. g. Slide pivot pin (Item 21) through pivot block (Item 11).
- Page 5 1.5 DRIVEN ASSEMBLY TO REEL______________________________________________________________________ 1. Turn quick height adjusters knob (S) 90° to unlock the Rotate 90° height adjustment for ease of assembly. 2. Apply Lubriplate Multi-Lube compound to the outside diameter of the bearing housing. 3. Align the blade assembly (C) and the roller assembly (D) with their corresponding mounting locations on the driven assembly (A).
- Page 6 1.7 ADJUSTING BELT _______________________________________________________________________________ 1. Place a deep well socket on eccentric nut (AB) and turn to tighten belt. [See Figure 11] NOTE: Use a deep well socket without the ratchet. The belt must be adjusted with hand pressure only. 2.
- Page 7 1.9 FINAL ASSEMBLY _______________________________________________________________________________ 1. Set height of cut to same height at both ends of reel. 2. Adjust nuts (AJ) as required to center blades between roller grooves. Tighten nuts (N). If any threads remain exposed after tightening nuts (N), add spacers (AR) as required to cover threads.
- Page 8 and record the results. 3. Keep in mind that the conditions and settings will vary from green to green and from one season to the next. 2. Your requirements will determine the final settings and they will be governed by the type and condition of the NOTE: Over grooming can cause severe damage to turf.
- Page 9 2.6 CLUTCH KNOB (22” GROOMER ONLY) ______________________________________________________________ Note: The 18” groomer is not equipped with a clutch knob and is designed to be always ON. 1. The Turf Groomer is equipped with a clutch to disengage the groomer blades and allow you to cut grass with the reel only.
-
Page 10: Turf Groomer
TURF GROOMER Serial No. All Turf Groomer Assembly Right Hand Groomer Shown (Left Opposite) 18" Groomer 22" Groomer... - Page 11 TURF GROOMER Item Part No. Qty. Description Serial Numbers/Notes 365226 Cover Plate > 2500229 Pulley Assembly 22” Groomers Only 365228 • Pulley, 28 Groove 22” Groomers Only 365229 • Bearing, Ball 22” Groomers Only 458461 • Snap Ring 22” Groomers Only 365232 •...
-
Page 12: Drive Assembly
TURF GROOMER Serial No. All Drive Assembly Right Hand Groomer Shown (Left Opposite) - Page 13 TURF GROOMER Item Part No. Qty. Description Serial Numbers/Notes > 4103100 Bracket, Groomer Roller 220302 Housing, Belt 365260 Link, Belt Adjusting 367162 Eccentric, Belt Adjusting 446142 Lockwasher, 3/8 Heavy 434030 Screw, 3/8-16 x 7/8” Socket Head 2500231 Cover, Belt Housing 338752 •...
- Page 14 TURF GROOMER Serial No. All Driven Assembly Right Hand Groomer Shown (Left Opposite)
- Page 15 TURF GROOMER Item Part No. Qty. Description Serial Numbers/Notes > 4103100 Bracket, Groomer Roller 338748 Bracket, Groomer Mounting 400186 Screw, 5/16-18 x 7/8” Hex Head 365233 Link, Roller Adjusting 444718 Locknut, 5/16-18 Center 453009 Flat Washer, 5/16 364061 Bracket, Adjusting Pivot 365342 Clamp, Backet Retaining 446136...
-
Page 16: Blade Assembly
TURF GROOMER Serial No. All Blade Assembly 1/4 Inch Spacing, Right Hand Groomer Shown (Left Opposite) - Page 17 TURF GROOMER Item Part No. Qty. Description Serial Numbers/Notes 367029 Locknut, 3/4-16 Hex Nyloc 367165 Spacer, 7/8 x 17/32” > 471221 Grease Fitting, 1/4-28 2500228 Driven Bearing Housing 241808 • Housing, Bearing 365229 • Bearing, Ball 458461 • Snap Ring 336962 •...
-
Page 18: Roller Assembly
TURF GROOMER Serial No. All Roller Assembly Item Part No. Qty. Description Serial Numbers/Notes 390899 22” Roller Tube, 1/4” Spacing 67911 and 67912 390900 22” Roller Tube, 1/2” Spacing 67913 and 67914 4116739 18” Roller Tube, 1/2” Spacing 67926 365330 Bearing, Ball 4169260 Shaft, Roller... - Page 19 TURF GROOMER Serial No. Quick Height Adjuster Item Part No. Qty. Description Serial Numbers/Notes 422502 Set Screw, 1/4-20 x 1/4” 365265 Link, Adjusting 163761 Knob Assembly 365271 • Bolt 365268 • Spring 365267 • Plunger 365266 • Bolt, Adjusting 365269 •...
- Page 20 A worldwide dealer network and factory trained technicians backed by Jacobsen Parts Xpress provide reliable, high-quality product support. When Performance Matters. ™ Jacobsen, A Textron Company 11108 Quality Drive, Charlotte, NC 28273 www.Jacobsen.com 800-848-1636...
