Textron JACOBSEN Eclipse 2 Technical/Repair Manual page 122

POWER TRAIN
2. Remove nut (2).
5
5
3. Loosen set screw (3) and remove the locking collar
(4).
4. Remove bearing and housing assembly (5).
5-14
Figure 5-31
3
4
Figure 5-32
2
TN0242
5. Remove grease seal (6) from the seal cover (7).
8
TN0243
6. Inspect bearing (8) for wear or damage. Remove the
bearing from the bearing housing (9) only if it is
necessary to replace the bearing.
6
Figure 5-33
9
Figure 5-34
4262930-Rev A
7
TN0244
TN0247
