Battery Tray and Power Module
Mount
Removal
See Figure 4-69.
1. Park the mower safely. (See "Park Mower Safely" on
page 1-5.)
2. Remove battery pack. (See "Battery Pack" on
page 4-56.)
1
14
Figure 4-69
NOTE
3. Label all wires before disconnecting to ensure
correct installation.
4. Disconnect harness connector (12).
5. Loosen the three nuts (2) and slide battery tray (4) to
gain access to the four screws (5).
4262930-Rev A
6. Remove four screws (5), lock washers (6), flat
7. Remove two rivets (10) and remove ceramic resistor
8. Remove three nuts (2), lock washers (1), flat
9. Remove battery tray (4) from power module mount
Disassembly and Assembly
See Figure 4-70.
2
3
4
3
5
4
6
7
8
9
10
11
1
2
3
4
12
13
Assembly Note
Inspect extension springs for wear prior to assembly.
Installation
Dielectric Grease (Jacobsen PN 365422)
Installation Notes
TN4442
• Install battery tray and power module mount by
• Apply dielectric grease (Jacobsen PN 365422) to any
washers (7), power module mount (14), spacers (8),
and power module mounting plate (13).
(11) from power module mounting plate (13).
washers (3), and carriage bolts (9).
(14).
2
1
1
3
4
3
3
1
8
5
7
Lock Nut (6) 5
Extension Spring (2) 6
Nut (8) 7
Lock Washer (4) 8
Figure 4-70
Required Materials
reversing the order of removal.
connectors removed.
ELECTRICAL
5
6
TN4441
Carriage Bolt (4)
Battery Tray
Clip
Screw (2)
4-69
