Textron JACOBSEN Eclipse 2 Technical/Repair Manual page 25

Front Roller Weights
18 Inch Grooved Machined Aluminum Roller
(PN 063318)
18 Inch Grooved Machined Steel Roller
(PN 068616)
18 Inch Heavy Smooth Roller with Scraper
(PN 068626)
18 Inch Light Smooth Roller
(PN 4108920)
22 Inch Grooved Assembly Steel Disc Roller
(PN 068527)
22 Inch Grooved Segmented Machined Aluminum
Roller (PN 068673)
22 Inch Light Smooth Roller
(PN 068530)
22 Inch Heavy Smooth Roller
(PN 068641)
22 Inch Grooved Machined Steel Roller
(PN 068613)
22 Inch Grooved Machined Aluminum Roller
(PN 068614)
Mower
Height-of-Cut Range (Bench Setting)
High-Profile Cut Yield
Low-Profile Cut Yield
Tournament Cut Yield
Super Tournament Cut Yield
Championship Cut Yield
Reel Diameter
Reel Composition
Width of Cut
Mower Weights (Without Grass Catcher)
Model 6336 (With Steel Groove Roller 68618)
Model 6337 (With Steel Groove Roller 68618)
Model 6340 (With Machined Aluminum Grooved Roller
68614)
Model 6341 (With Machined Aluminum Grooved Roller
68614)
Model 6345 (With Steel Groove Roller 68618)
Model 6346 (With Steel Groove Roller 68618)
Model 6349 (With Machined Aluminum Grooved Roller
68614)
Model 6350 (With Machined Aluminum Grooved Roller
68614)
4262930-Rev A
SPECIFICATIONS AND GENERAL INFORMATION
lb (kg)
lb (kg)
lb (kg)
lb (kg)
lb (kg)
lb (kg)
lb (kg)
lb (kg)
lb (kg)
lb (kg)
in. (mm)
in. (mm)
in. (mm)
in. (mm)
in. (mm)
in. (mm)
in. (mm)
Hardened High-Manganese Carbon Steel
in. (cm)
lb (kg)
lb (kg)
lb (kg)
lb (kg)
lb (kg)
lb (kg)
lb (kg)
lb (kg)
7 (3.18)
16 (7.26)
20 (9.07)
6 (2.72)
10 (4.54)
8 (3.63)
7 (3.18)
18 (8.16)
18 (8.16
8 (3.63)
1/16–7/16 (1.6–11.1)
5/32–7/16 (3.96)
1/8–7/32 (3.17)
3/32–5/32 (2.38)
5/64–7/64 (1.58)
1/16 –7/64 (1.58)
5 (127)
18 (457), 22 (557.5)
254 (115.22)
257 (116.6)
265 (120.2)
268 (121.6)
274 (124.3)
277 (125.6)
285 (129.3)
288 (130.6)
2
