Gen-Set Models - Textron JACOBSEN Eclipse 2 Technical/Repair Manual

SAFETY
1
5. Disconnect battery pack connector (5).
)
6
7
6. Lower and hold the kickstand (7) against the ground.
Grab lower part of handle at base (6), and pull up
and back until the mower rests securely on the
kickstand.
1-6
5
Figure 1-6
Figure 1-7

Gen-Set Models

See Figures 1-8 through 1-10.
Before cleaning, adjusting, or repairing this
equipment, disengage all drives, engage park
brake, and stop engine to prevent injuries.
When performing maintenance other than
adjustments that require the engine to be
running, disconnect gen-set connector, remove
the spark plug wire, and place the wire away from
the plug to prevent accidental starting and bodily
TN4414
injury.
2
1
1. Release the Operator Presence Control (OPC) bail (2).
2. Engage the park brake lever (1).
3. Move key switch (3) to the off position and remove
key.
TN4454
!
WARNING
Figure 1-8
4262930-Rev A
3
TN4388
