SPECIFICATIONS AND GENERAL INFORMATION
Engine
Repair Specifications
Engine Mounting Carriage Bolt Torque
Electrical
Test and Adjustment Specifications
Ceramic Resistor Resistance at 68° F
120 Ohm Resistor Connector Resistance at 68° F
2
Throttle Potentiometer Low End Resistance at 68° F
Throttle Potentiometer High End Resistance at 68° F
Bail Potentiometer Resistance at 68° F
Repair Specifications
Battery Pack Fuse Nut Torque
Generator Engine Shaft Screw Torque
Generator Mounting Screw Torque
Generator Adapter Plate Mounting Screw Torque
Generator Cover Mounting Screw Torque
Power Train
Check and Adjustment Specifications
Traction (Transfer) Drive Belt Maximum Deflection
with 3.5–6.3 lb (15.6–28.0 N) of Force Applied at the
Midpoint Between Pulleys.
Traction (Final) Drive Belt Maximum Deflection with
12.5–15.2 lb (55.6–67.6 N) of Force Applied at the
Midpoint Between Pulleys.
Brakes
Repair Specifications
Park Brake Lever Actuating Force
Park Brake Band—Anchor Pin Center-to-Center
Distance
(Park Brake Released)
2-8
lb-ft (N·m)
ohms
ohms
ohms
ohms
ohms
lb-in. (N·m)
lb-ft (N·m)
lb-in. (N·m)
lb-ft (N·m)
lb-in. (N·m)
in. (mm)
in. (mm)
lb (kg)
in. (mm)
13 (17.7)
5 ± 5%
120 ± 10%
18.9–35.1
3710–6890
3640–6760
25 (2.82)
20.4 (27.7)
68 (7.7)
14.4 (9.5)
68 (7.7)
0.14 (3.5)
0.10 (2.5)
10 (4.5)
1.50 (38)
