Turning on the Instrument

2.1
The AD INSTRUMENTS AD8000 models are capable of approximately 3.5
hours of continuous operation with fully charged. It can also work while
charging with AC/DC adapter or vehicle cigarette lighter.
Warning: When using vehicle cigarette lighter, make sure that the supply is
rated for a minimum of 60 Watts at 12 VDC, and the socket is clean without
any dirt or debris. If the adapter plug becomes hot to touch during
charging, Please discontinue using it immediately.
Press the ON/OFF button on the front panel for 2 seconds toturn on the
spectrum analyzer. Wait for about 10 seconds to enter the measurement
interface to start measuring.
Main Menu Keys Backlight Control ON/OFF Button
Fig. 2-1 Spectrum Analyzer Interface
Main
Function Keys
Sub-Menu Keys
Number Keys
7
