AD8000 Series Spectrum Analyzer Instruction
Manual
No.
The order of 2 ends of direction network cable is the same, which is 568A
or 568B; the ends of crossover cable are 568A and 568B differently, which
is that 1and 3 interchange, and 2 and 6 interchange.
It shows the simplest connection way above. Actually, one PC could
connect with multiple AD8000, and one AD8000 could also connect to
multiple PCs that they could constitute a mesh topological structure.
202
568A
1 Green, white
2 Green
3 Orange, white
4 Blue
5 Blue, white
6 Orange
7 Brown, white
8 Brown
Network Cable
1 <----> 1
2 <----> 2
3 <----> 3
4 <----> 4
5 <----> 5
6 <----> 6
7 <----> 7
8 <----> 8
568B
Orange, white
Orange
Green, white
Blue
Blue, white
Green
Brown, white
Brown
Crosswire
1 <----> 3
2 <----> 6
3 <----> 1
4 <----> 4
5 <----> 5
6 <----> 2
7 <----> 7
8 <----> 8
