5.1.3 Control CH Power

Select 'Control CH Power' to enter the menu of control channel power.
The measurement shows the control channel power of key physical layer
and 'constellation' in the measurement result.
1) Bandwidth
Select 'Bandwidth' to enter. It include 6 frequencies: 1.4, 3, 5, 10, 15 and
20Mhz.
Fig. 5-9 Control Channel Power Menu
Fig. 5-10 Bandwidth
