11.3.3 Input/Output Index

Model
RF Input
Input Port
Input
Impedance
Typical<1.8 (10MHz
VSWR
Tracking Source (Option)
Output Port
Output
Impedance
VSWR
Frequency
Range
Frequency
Stability
Level Range
Level Step
Harmonic
Spurious
Level Accuracy
Anharmonic
Spurious
AD8000A
～3000MHz
Attenuator≥10dB)
100kHz-3000MHz 25MHz～4000MHz 25MHz～6000MHz
±1.5dB
AD8400A
N type
50Ω
Typical<1.8
( 10MHz– 3000MHz,
Attenuator≥10dB)
Typical<2.0 3000MHz
–4000MHz,
Attenuator≥10dB)
N type
50Ω
<2.0
±2ppm
-30dBm～0dBm
1dB
-20dBc
-30dBc
AD8600A
Typical<1.8
( 10MHz– 3000MHz,
Attenuator≥10dB)
Typical<2.0
(3000MHz – 6000MHz
Attenuator≥10dB)
±2dB@20℃
