AD8000 Series Spectrum Analyzer Instruction
Manual
Main Functions
1.1
The AD8000 is an integrated multi-functional analyzer that eliminates the
need to carry and learn multi instrument. Except spectrum analysis
function, the AD8000 is also configured functions including power
measurement, occupied bandwidth measurement, interference analyzer,
tracking generator and a high accuracy GPS receiver for location stamping.
The bright 6.5-inch color display provides visibility even in hard light. Built-
in Li-Ion battery can work more than 3.5 hours.
The internal 1G flash memory is large enough to store approximately 2,000
traces or setup files. Measurements data and setup files can also be stored
in a USB flash disk or transferred to PC via the LAN cable.
Workbench software is based on PC platform. It could generate
measurement report, check and manage data and history data, and analyze
cursors, limit line, measurement curve and etc.
This device is produced according to ISO9001 international quality
management system standard by AD INSTRUMENTS. The ISO9001 quality
system was registered and certificated in 1996.
Preventive Maintenance
1.2
AD8000 series preventive maintenance includes the unit surface cleaning, RF
connectors and all accessories cleaning. Clean unit surface with a soft, lint-
free cloth dampened with water.
Caution: To avoid damaging the display or case; do not use solvents or
abrasive cleaners.
Clear the RF connectors and center pins with a cotton swab dampened with
denatured alcohol. The fingers of the N(f) connectors and the pins of the
N(m) connectors should be unbroken and uniform in appearance. If you are
unsure whether the connectors are undamaged, gauge the connectors to
confirm that the dimensions are correct. The test port cable should be
uniform in appearance, and not stretched, kinked, dented, or broken.
