AD8000 Series Spectrum Analyzer Instruction
Manual
MARK
PEAK
CPL
SAVE
SYS
ENTER
4 '↑ ↓' Direction Keys
'↑ ↓' direction keys are at the center of the key area at the right of the
screen. They are used to change the editing parameter or select item from
the list. It is also used to move the marker.
5 Knob
The knob is at the center of the key area at the right of the screen, used for
change the editing parameter or select item from the list. It is also used to
move the marker. Pressing the knob has the same effect of pressing ENTER.
6 Number Keys
'0～9' number keys, '+/-' symbol keys, and '.' key are at the key area at the
right of the screen, used to complete number editing
Detail operation of each key would be described in the following chapters.
Mark: Active the mark measurement function to
open and shut, reading and comparison of the
frequency mark.
Peak: Active the peak menu to do the operations such
as opening, closing, reading, comparing the peak
value and etc.
complex function key: set parameters such as RBW
Save: active file menu, could do operations such as
saving trace, image and status file, check and manage.
System: active system menu. It is used to set system
parameters, display system information, complete
system update and etc.
Confirm: used to confirm editing parameters or
current operation
9
