Limit
2
The main contents of Channel power includes channel power and power
density, so there are the limits of channel power and power density.
Limit is set as the figure below. Press the soft key of the limit, and the
following dialog box will pop up. The master switch controls all limit
measurement. When turning off, all settings are not editable, shown as
below:
Only when the master switch and one of the measurement limit switches
are turned on, the limit measurements can be measured and set.
The limit settings dialog box is shown as below after turning on the limit.
Fig. 3-75 Master Switch of Limit OFF
