Component Location - Textron Jacobsen InCommand PGM 22 Technical/Repair Manual

POWER TRAIN

Component Location

See Figure 5-1.
5
1 Traction/Reel Drive Clutch
2 Traction/Reel Drive Chain
Case
3 Traction Drum/Differential
Assembly
5-2
1
2
11
10
9
8
4 Clutch/Input Shaft and
Sprocket
5 Traction Drive
Sprocket/Planetary Gear
Assembly
Figure 5-1: Drive Train Component Location
4
5
6
7
6 Chain Guide
7 Reel to Traction Drive
Chain
8 Reel Clutch
9 Reel Sprocket
3
TN0155, 0004, 0087
10 Chain Guide
11 PTO to Reel Chain
4157082 First Edition
