4. Slide OPC bail (2) to the left and engage.
Engine speed will increase, drive mechanism will
engage, and wheels will begin to turn.
Does the drive mechanism engage?
NO Stop the engine immediately and repair the
system.
5. Release the OPC bail.
Bail will disengage, engine speed will return to idle,
and drive mechanism will stop.
Does the drive mechanism continue turning after
the OPC bail is released?
YES Stop the engine immediately and repair the
system.
6. Push E-stop switch (3) to stop engine.
