POWER TRAIN
Disassembly and Assembly
See Figure 5-56.
1
5
1 Grease Fitting
2 Grease Fitting
Assembly Note
• Install new oil seals (3 and 5).
• Apply lithium grease NLGI Grade 2 to grease fitting
(1) after assembly is completed.
• Apply Lubriplate
assembly.
5-20
2
8
3 Oil Seal
4 Bearing Cup and Cone (2)
®
grease to grease fitting (2) after
4
3
7
5 Oil Seal
6 Frame
Figure 5-56
4
5
6
TN0120
7 Handle Stud (Press-Fit)
8 Bushing (Press-Fit)
