Installation
See Figures 5-57 through 5-64.
1 2
5
Figure 5-57
1. Install the right side frame (5) to the front and rear
crossbars using four screws (1) and lock washers (2).
2. Install nut (3) and lock washer (4).
6
Figure 5-58
NOTE
Pack bearing with lithium grease NLGI Grade 2 before
installation.
3. Install bearing (6) on reel shaft.
4157082 First Edition
1 2
4. Install spring (8), washer (7), and nut (9) on the reel
3 4
shaft.
TN0113
TN0119
NOTE
Pack bearing with Lubriplate
5. Install bearing (11) and spacer (10) on the traction
drum shaft.
POWER TRAIN
8
7
9
Figure 5-59
11
10
Figure 5-60
®
grease before installation.
TN0112
5
TN0118
