ENGINE
12
3
NOTE
Label all wires before disconnecting to ensure correct
installation.
7. Remove nut (10) and disconnect ground wire (9).
8. Disconnect engine on/off switch wire (12).
9. Disconnect engine harness wire (11).
13 14
10. Remove four screws (13) and lock nuts (14), and
remove front half of clutch cover (15).
3-8
9
11
Figure 3-11
13 14 13 14
15
Figure 3-12
10
TN0072
NOTE
Use a strap wrench to prevent clutch from turning while
removing screws.
11. Remove three socket-head screws (20) and lock
washers (21).
12. Remove screw (17), lock washer (18), flat washer
(19), and clamp (16) from engine.
22 23
13 14
TN0008
NOTE
Support engine before removing mounting hardware.
13. Remove two screws (22) and lock washers (23) from
rear of engine mounting plate (24).
16
20 21
Figure 3-13
24
Figure 3-14
