Turf Groomer Shaft Assembly
Disassembly
See Figures 10-47 through 10-50.
!
CAUTION
To prevent personal injury and damage to cutting
edges, handle the vertical mower shaft assembly
with extreme care.
1
Figure 10-47
1. Measure and record the distance between the face of
the locking collar and the bearing face (1) on both
ends of the shaft assembly.
4
3
2
Figure 10-48
2. Loosen set screw (5) in locking collar (4) and remove
bearing shaft assembly (2) and key (3) from both
ends of the shaft.
4157082 First Edition
3. Remove the locking collar (6), two spacers (7),
TN0338
4. Remove two spacers (11) from the shaft (12).
5. Loosen the set screw (14) and remove the locking
5
TN0339
8
9
8
7
6
Figure 10-49
blades (8), and spacers (9) from shaft (10).
12
11
Figure 10-50
collar (13) from the shaft (12).
ACCESSORIES
10
8
9
TN0340
13
14
TN0341
10-27
10
