ACCESSORIES
Drive Assembly
Removal
See Figures 10-31 through 10-34.
1. Park the mower safely. (See "Park Mower Safely" on
page 1-6.)
1
7
8
2. Remove hex head screws (5) and lock washers (6).
3. Remove hex head screw (7), lock washer (8), and
clutch control knob (1).
4. Remove lock nuts (2), flat washers (3), and belt cover
(4).
9
10
5. Remove hex head screw (9) and lock washer (10).
10
6. Remove eccentric adjuster nut (11), idler pulley (12),
and spacer (13).
7. Remove drive belt (14).
10-18
2
3
4
5
6
Figure 10-31
11
12
13
14
Figure 10-32
8. Remove set screw (21) and drive pulley (20).
9. Loosen groomer shaft set screw (18) and roller shaft
set screw (19).
10. Remove hex head screw (15), spacer (16), and lock
nut (17).
TN0311
22
11. Remove drive assembly (22) from machine.
TN0333
15
16 17
21
20
Figure 10-33
Figure 10-34
4157082 First Edition
18 19
TN0334
TN0335
