Textron Jacobsen InCommand PGM 22 Technical/Repair Manual page 89

5
6
Figure 6-11
2. Slide one handle tube (5) onto stud (6). Press other
handle tube in until end of tube slips over end of stud.
3. Support handle assembly.
7
12 13 14
11
Figure 6-12
NOTES
• Support handle assembly until mounting hardware is
installed.
• Steps 4 through 6 apply to both sides of the handle
assembly.
4. Install torsion spring (11), washer (8), and retaining
ring (9) on stud (10).
5. Secure handle stop (7) to frame using screw (12),
lock washer (13), and washer (14).
4157082 First Edition
TN0036
6. Connect torsion spring (16) to handle stop (15).
8 9
24
10
TN0034
NOTE
Connect wires to same connector as noted during
removal.
7. Install ground wire (17) to stud using nut (22).
8. Connect wire (24) to engine on/off switch.
9. Connect wire (23) to engine harness connector.
10. Install clamp (18) to engine using a screw (19), lock
11. Connect throttle cable to engine throttle plate. (See
12. Connect clutch cable to engine throttle plate. (See
13. Connect both park brake cables to brake bands. (See
HANDLE AND CONTROLS
16
15
Figure 6-13
17
23
Figure 6-14
washer (20), and flat washer (21).
"Throttle Cable" on page 3-5.)
"Clutch Control Cable" on page 5-4.)
"Park Brake Cable" on page 7-5.)
TN0033
18
19 20 21
6
22
TN0032
6-5
