Textron Jacobsen InCommand PGM 22 Technical/Repair Manual page 149

1 1/4" Lock Washer
2 1/4-20 x 2" Hex Head Screw
3 3/8-24 x 1/2" Hex Head Screw
4 3/8" Lock Washer
5 3/8" Flat Washer
6 Clutch Control Plate
7 3/8-24 x 1" Hex Head Screw
8 3/8" Lock Washer
9 Spacer Knob
10 Washer
11 Spring
12 Drive Hub
13 Hub
14 3/16 x 1-1/4" Roll Pin
15 16-Groove Pulley
16 Bearing
17 Snap Ring
18 5/32 x 3/4" Groove Pin
19 1/8" Grease Fitting
20 Height Adjustment Nut
21 5/16" Hex Nut
22 5/16" Lock Washer
23 Strap
24 3/32 x 1-3/4" Cotter Pin
25 3/16 x 1" Roll Pin
26 Shaft
27 Spacer
28 Gasket
29 Hub
30 Hub Seal
31 1/4" Lock Washer
32 1/4-20 x 3/4" Socket Head Screw
Assembly Notes
• Install new gasket (28).
• Apply lithium grease NLGI Grade 2 to stud (63)
during assembly.
• Apply lithium grease NLGI Grade 2 to grease fitting
(19) after assembly.
• Torque hex head screw (47) to 20 lb-ft (27 N•m).
4157082 First Edition
33 5/16" Lock Nut
34 14-20 x 3/4" Socket Head Screw
35 Right-Side Roller Bracket
36 Right-Side Mower Bracket
37 Special Washer
38 3/8" Lock Washer
39 3/8-16 x 1" Hex Head Screw
40 Spacer
41 1/4-20 x 5/8" Socket Head Screw
42 Snap Ring
43 Bearing
44 15-Groove Pulley
45 Eccentric Adjuster Nut
46 3/8" Lock Washer
47 3/8-16 x 1-1/2" Hex Head Screw
48 1/4-20 x 1/4" Set Screw
49 10-Groove Pulley
50 Belt
51 1/4" Flat Washer
52 1/4" Lock Nut
53 Belt Cover
54 1/4" Lock Nut
55 1/4" Lock Washer
56 5/16-18 x 2-1/4" Hex Head Screw
57 Adjustment Bracket Pivot
58 Height Adjustment Bracket
59 Spacer
60 5/16" Lock Nut
61 Spacer
62 Adjustment Bracket Pivot
63 Stud
64 Roller Adjustment Knob
ACCESSORIES
10
10-21
