ACCESSORIES

Troubleshooting

Turf Groomer

Condition
Turf groomer does not engage when clutch
is engaged.
Turf groomer does not reach full speed.
Turf is being damaged when turf groomer
is engaged.
Premature wear or failure of belt, pulleys,
and/or bearings.
10
10-4
Probable Cause
Drive belt not properly tensioned.
Drive belt worn, stretched, or damaged.
Clutch shaft roll pin loose or broken.
Drive shaft roll pin loose or broken.
Clutch spring broken.
Turf groomer height-of-cut set too low.
Turf groomer shaft key broken or missing.
Turf groomer drive pulley set screw loose
or missing.
Reel clutch not engaged.
Traction/reel drive clutch faulty.
Front roller not properly aligned with turf
groomer blades.
Turf groomer drive belt not properly
tensioned.
Turf groomer drive belt worn, stretched, or
damaged.
Grooming too frequently.
Turf groomer height-of-cut set too low.
Drive belt is adjusted too tight.
Bearings not lubricated properly.
Remedy
Adjust drive belt tension. (See "Turf
Groomer Drive Belt Tension
Adjustment" on page 10-6.)
Replace drive belt. (See "Drive Belt" on
page 10-17.)
Replace clutch shaft roll pin. (See "Drive
Assembly" on page 10-18.)
Replace drive shaft roll pin. (See "Drive
Assembly" on page 10-18.)
Replace clutch pin. (See "Drive Assembly"
on page 10-18.)
Adjust height-of-cut. (See "Turf Groomer
Height-of-Cut Adjustment" on
page 10-7.)
Replace turf groomer shaft. (See "Turf
Groomer Shaft Assembly" on
page 10-27.)
Tighten or replace groomer shaft drive
pulley set screw. (See "Drive Assembly"
on page 10-18.)
Engage reel clutch. See Operator's
Manual.
Replace clutch. (See "Engine and Clutch"
on page 3-7.)
Adjust front roller. (See "Front Roller" on
page 10-26.)
Adjust belt tension. (See "Turf Groomer
Drive Belt Tension Adjustment" on
page 10-6.)
Replace drive belt. (See "Drive Belt" on
page 10-17.)
Reduce frequency of grooming.
Adjust turf groomer height-of-cut. (See
"Turf Groomer Height-of-Cut
Adjustment" on page 10-7.)
Adjust drive belt tension. (See "Turf
Groomer Drive Belt Tension
Adjustment" on page 10-6.)
Replace damaged or faulty components
and lubricate at the intervals indicated
in the Operator's Manual.
