12.9 Device Settings

Switch on the direct print module and the display shows the main
menu.
Press key to access the function menu.
Press key as long as you arrive the Device Settings menu.
Press key to select the menu.
Off: The complete print memory is deleted.
Keep graphic: A graphic res. a TrueType font is transferred to the
direct print module once and stored in the direct print module internal
memory. For the following print order only the modified data is
transferred to the direct print module. The advantage is the saving of
transmitting time for the graphic data.
The graphic data created by the direct print module itself (internal
fonts, bar codes, ...) is generated only if they were changed. The
generating time is saved.
Delete graphic: The graphics res. TrueType fonts stored in the
internal memory is deleted but the other fields are kept.
Press key to arrive the next menu item.
Indication of the font used in the direct print module.
The following possibilities are available:
ANSI character set / Codepage 437 / Codepage 850 / GEM German /
GEM English / GEM French / GEM Swedish / GEM Danish.
Press key to arrive the next menu item.
Layout dimension only: The parameters for layout length, gap
length and layout width can be transferred to the printing system. All
other parameter settings are to be made directly at the printing
system.
On: Sending parameters such as print speed and contrast via our
creation software to the printing system. Parameters which are set
directly at the printing system before are no longer considered.
Off: Only settings made directly at the printing system are considered.
Press key to arrive the next menu item.
On: An acoustic signal is audible when pressing a key.
Valur range: 1 ... 7.
Ein:
Off: No signal is audible.
Setting of display contrast.
Value range: 35 ...85.
Press key to arrive the next menu item.
Selection of language in which you want to display the text in the
display.
At the moment the following languages are available: German,
English, French, Spanish, Portuguese, Dutch, Italian, Danish, Finnish,
Polish, Czech, Russian and Chinese (option).
