Module 2; Instrument Overview; Assembling Your 831C Slm - Larson Davis SoundAdvisor 831C Reference Manual

2

Module 2

In this module:
2.1

Assembling Your 831C SLM .................................................................................................... 9

2.1.1 Connecting the Microphone and Preamplifier
2.1.2 Connecting the Preamplifier to Meter
2.1.3 Disconnecting the Preamplifier
2.1.4 Preparing the 831C for Long Term Storage
2.2 Powering the 831C SLM ........................................................................................................ 11
2.2.1 Using Battery Power
2.2.2 Using External Power
2.2.3 Understanding 831C Power Events and Indications
2.2.4 Powering On or Off
2.2.5 Using the Power Control Page
2.3 Instrument Hardware Overview .......................................................................................... 16
2.3.1 Using 831C Buttons
2.4 Display Elements Overview .................................................................................................. 19
2.4.1 Changing Display Color Themes
2.4.2 Using Tabs and Pages
2.4.3 About Status Bar Icons and Indicators
2.4.4 Main Menu Overview
2.4.5 Tools Menu Overview
2.4.6 Power Control Menu Overview
2.1 Assembling Your 831C SLM
2.1.1 Connecting the Microphone and Preamplifier
SoundAdvisor Model 831C

Instrument Overview

T
his module describes the hardware and display components that make
the SoundAdvisor Model 831C the best meter for monitoring sound.
In this section:
2.1.1 Connecting the Microphone and Preamplifier
•
• 2.1.2 Connecting the Preamplifier to Meter
• 2.1.3 Disconnecting the Preamplifier
2.1.4 Preparing the 831C for Long Term Storage
•
DO NOT handle the microphone and preamplifier without
CAUTION
observing the following items:
• Ground yourself so the pogo pin is not exposed to static
shock.
• Never use excessive force.
Assembling Your 831C SLM 9
