Table A.7 (Continued)
Test Conditions
Output Connector: Switchcraft TA5M 5-Pin male
Table A.8 Output Connector Key
Pin
1 Signal Ground
2 Signal Output
3 Power Supply + 35 Volts
4 Preamp sense
5 No Connection
Shell Connect to preamp housing
SoundAdvisor Model 831C
Signal
All values are at 23° C, 50% RH, 35 Volt supply, 3 m
(10') cable and equivalent microphone of 12 pF
unless otherwise stated.
