Summary of Contents for Larson Davis AudCal

  • Page 1 QUICKSTART AUDCAL AUDIOMETRIC CALIBRATION...
  • Page 2 coupler Systems of AEC100 AEC201 377C13 mastoid equipment: SYS014 SYS015 SYS016 SYS017...
  • Page 3 1 AudCal system equipment SoundAdvisor Model 831C SLM PRM831 preamplifier CAL250 calibrator 377A15 1” prepolarized mic 377C13 1/2” prepolarized mic (AEC201 only) AEC100 or AEC201 coupler mastoid EXC006 preamp cable...
  • Page 4 ADP008A adapter for 1” mic earphone retaining ring weight assembly with mass handle IEC Type 1 adapter & weight bag (with AEC201) pillow support board mastoid weight windscreen...
  • Page 5: Setup Equipment

    AudCal app from Google play or Apple app store Connect to G4 LD Utility via TCP/IP to AudCal App via WiFi on 831C: 831C WiFi should be ON and navigate Tools  Communication in Access Point mode...
  • Page 6 5 Setup case for testing stack earphone retaining ring and weight assembly on coupler inside case during test preamp cable retaining ring/ weight bag weight assembly coupler/mic windscreen artificial mastoid adapters cables calibrator etc. WIFI dongle USB cable...
  • Page 7 For more information, refer to the AudCal Reference Manual located on the USB drive or online at larsondavis.com IAUDCAL.02 REV A...
  • Page 8 AUDCAL AUDIOMETRIC CALIBRATION...
