Larson Davis SoundAdvisor 831C Reference Manual page 40

About the Preamplifier Interface Page
FIGURE 4-6 Live Tab: Preamplifier Interface Page
1.
2.
About the Power Page
FIGURE 4-7
Live Tab: Power Page
1.
2.
SoundAdvisor Model 831C
Use the information on the preamplifier interface page to validate the proper operation of
the meter. Figure 4-6 shows how this page's display may differ, depending on the preamp
installed.
3.
The Power page shows the meter status items as shown in Figure 4-7.
1.
The current date and time can easily be seen on
this page.
2.
Voltage of the battery and the USB external
3.
power source can be tracked here.
3.
See the section "Battery States On the Power
4.
Page" on page 36 for important battery state
reference information.
5.
4.
Checking the internal temperature of the meter
here periodically is good safety practice.
5.
Amount of internal memory currently available.
SoundAdvisor 831C Display In SLM Mode
1.
Current preamplifier.
2.
The voltage of the
preamplifier connected is
shown in VDC.
3.
When a 426A12
preamplifier is installed this
page provides information
like temperature and
humidity as well as
desiccant maintenance
information.
