A.1.6 Input Specifications
A.1.7 USB Client Interface Specifications
A.1.8 USB Host Interface Specifications
SoundAdvisor Model 831C
Display:
• TFT full color LCD, 240 by 320 dot matrix
• White backlight with adjustable brightness and on–time
• Touch screen to assist in data navigation and measurement control
• Multiple color themes for various lighting conditions
Display update rate: ≤ 1 s
Lock: User interface may be locked and unlocked
Languages: Czech, English, French, German, Italian, Norwegian, Portuguese,
Russian, Spanish, Swedish, Turkish
Connector: Latching 5-pin circular connector, mates to PRM831 or EXCxxx cables
Preamplifier Supply: 36 volt at 5mA available to power preamplifier
Input Impedance: ≥ 100kΩ || 300 pF
Direct Input: Absolute maximum of ±35 V, DC bias readout 0 to +35 V
Gain Control: Selectable 0 or +20 dB gain
Full Scale Input 0 dB Gain: ±14.14 Vpeak AC
Full Scale Input +20 dB Gain: ±1.414 Vpeak AC
ICP Input (use ADP074): Constant current of 4 mA, maximum voltage of 28 V
Sample Rate: 51,200 sps
Type: USB 2.0 High–Speed Mini–B connector
Power Draw: ≤ 500mA from PC, USB Hub, or PSA029
Supported Hosts:
• Computer with SLM Utility-G4
• Ethernet Dock 831INT-ET
• NoiseTutor
• Computer with custom software using SWW-G4-SDK or SWW-G4-WIN
Type: USB 2.0 High-Speed, standard A connector
Supported Devices:
• USB Flash Memory Drive, up to 32GB FAT-32 Format, PN 831-M
• Ethernet Adapter, 1G/100M/10M, PN DVX012
• Ethernet Adapter & USB Hub, 1G/100M/10M, PN DVX013
• WiFi Wireless Adapter, Edimax EW-7811Un, or D-Link DWA-121, PN DVX014
(WPA/WPA2 encryption)
