Appendix B Connect the instrument to a network
B

Instrument and computer connections

Instrument and computer connections
1
2
3
4
5
6
Figure 25 Instrument back panel
USB ports
1
Wi-Fi dongle port
2
Ethernet port
3
RS-232 port (service use only)
4
ON/OFF switch
5
Power inlet receptacle
6
196
