Perform ROI/uniformity, background, dye, and normalization calibrations for the TaqMan
8. (For calibrations that pass) Select an option.
Option
Details
Transfer EDS
Reject results
Accept results
If the results are accepted and the calibration file is saved, previous calibration files associated with
the combination of the instrument and the block will no longer be used.
9. (For calibrations that fail) Select an option.
Option
Details
Transfer EDS Transfer the calibration file to Connect, a USB drive, or a network drive (recommended
Close
See "Troubleshoot calibration failure"
10. Unload the TaqMan
CAUTION! PHYSICAL INJURY HAZARD. During instrument operation, the TaqMan
Card temperature can reach 100°C. Allow it to cool to room temperature before handling.
Note: Use Smart Help if the instrument does not eject the array card (see "Request technical
support with Smart Help"

View the calibration images

The instrument performs the ROI, uniformity, and background calibrations in sequence. You can view
the calibration images after the background calibration is complete.
1. In the home screen, tap
reminders.
The Status and Reminders screen is displayed.
2. Tap a calibration type in the table, then tap View.
3. Tap a calibration date in the table, then tap View.
The following details are displayed:
QuantStudio ™ 6 Pro Real-Time PCR System and QuantStudio
View the calibration images.
Transfer the calibration file to Connect, a USB drive, or a network drive.
The calibration file is deleted.
The calibration file is saved.
View the calibration images.
for troubleshooting).
The calibration file is deleted.
on page
™
Array Card from the instrument.
on page 172).
(Settings)4Maintenance and service4Calibration4Status and
Chapter 7 Calibrate and verify instrument performance
Description
Description
95.
™ 7 Pro Real-Time PCR System User Guide
7
™ Array Card block
™
Array
101
