Depth: 52.5 cm
1

Instrument and computer clearances

During instrument installation and maintenance, it is necessary to access the back of the instrument. If
the back of the instrument faces a wall, ensure that there is sufficient clearance on the bench to rotate
the instrument for access.
IMPORTANT! For safety, the power outlet for the instrument must be accessible.
Component
Instrument
[1]
Computer
[1]
Co-locating the computer with the instrument is optional.
QuantStudio ™ 6 Pro Real-Time PCR System and QuantStudio
1
Top
30.5 cm (12 in.) 30.5 cm (12 in.)
— 15.25 cm (6 in.)
™
Appendix A Instrument specifications and layout
Front Sides
7 Pro Real-Time PCR System User Guide
Instrument dimensions
Back
— 15.25 cm (6 in.)
— 15.25 cm (6 in.)
A
189
